QFY-120 air filter regulator
QFY - 120 (setter) air filter regulator series is one of pneumatic instrument auxiliary unit, it will be the air compressor output from 1 to 0.3 MPa compressed air after purification, QFY - 120 can be reduced pressure to fixed output pressure range of 0 ~ 0.14 MPa, as for all kinds of instrument air pressure of auxiliary devices, and other auxiliary device of pneumatic equipment.
Technical parameter:
1,Air pressure:0.3~1Mpa
2,Output pressure:0~0.14Mpa
3,Pressure characteristic:when the air pressure change is ±0.1Mpa,output pressure change is ≤1.5%
output is upper limit value.
4,Flow characteristic: when output flow change is 0~0.3m3/h,output pressure change is ≤7%(upper output value).
6. Ambient temperature:-30~+60℃
8.Pipe thread:M10×1
9.Instrument weight:1.5kg
