Home > Industrial Equipment & Components > Bearing > Spherical Roller Bearing > MZ15G-MZ70G Overrunning Clutch With Good Quality for Indusrial Machine

MZ15G-MZ70G Overrunning Clutch With Good Quality for Indusrial Machine

Name: MZ15G-MZ70G Overrunning Clutch With Good Quality for Indusrial Machine
Brand: SUMA
SKU: 140280458
Availability: InStock

Changzhou Suma Precision Machinery Co., Ltd.

MZ15G-MZ70G Overrunning Clutch With Good Quality for Indusrial Machine thumbnail-1

MZ15G-MZ70G Overrunning Clutch With Good Quality for Indusrial Machine photo-1

US$ 60 - 800 MOQ: 1 Piece

Key Specifications

Get Latest Price

Brand Name:

SUMA

Bore Size:

15, 70

Outside Diameter:

68, 175

Contact Supplier Request Quote Chat Now

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai ; Ningbo

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Brand Name SUMA

Bore Size 15, 70

Outside Diameter 68, 175

Model Number MZ-G

Precision Rating P6

Seals Type sealed

MZ-G SERIES CAM CLUTCH: MZ15G-MZ70G overrunning Clutch with Good Quality for Indusrial Machine

MODELS MZ 15G TO MZ 70G

For General Applications Installation and Usage

1. When mounting sprockets or gears to the outer race, use the outer race outer dimension (dimension B) to make a centering flange in the gear or sprocket. Then attach firmly with bolts of tensile strength 10.9 or greater to the tapped holes in the outer race.

2. Please refer to MZ Series for usage and other types of installations.

Parameters

Capacities

Model	Torque Capacity (N·m)	Max.Overrunning (r/min)		Max. Indexing (cycle/min)	Drag Torque (N·m)
		Inner Race	Outer Race
MZ15G	186	2,200	900	150	0.20
MZ17G	215	2,000	800	150	0.20
MZ20G	323	1,900	700	150	0.29
MZ30G-22	735	1800	500	150	0.39
MZ30G-25
MZ30G
MZ35G	1,080	1,700	300	150	0.49
MZ45G-40MZ45G	1620	1700	300	150	0.69
MZ60G-50
MZ60G-55	2110	1600	250	150	0.98
MZ60G
MZ70G-65	3040	1300	250	150	1.27
MZ70G

Dimensions

Bore size			A	C	B (h7)	F	E	K	PCD D	S	H-M No.of Tapped Holes ×Size ×Pitch	Weight (kg)
Dia. (H7)	Keyway	Chamfer J
15	5×2.3	0.8	55	53	68	25	47	1.3	58	10	6-M5×0.8	1.3
17	5×2.3	0.8	63	61	75	28	52	1.3	64	10	6-M5×0.8	1.7
20	5×2.3	0.8	64	62	80	30	55	1.3	68	12	6-M6×1.0	1.9
22	8×3.3	1.0	70	68	100	45	75	1.3	88	16	6-M8×1.25	3.2
25	8×3.3	1.0
30	10×3.3	1.0
35	10×3.3	1.0	78	76	110	50	80	1.3	95	16	6-M8×1.25	4.4
40	12×3.3	1.3	87	85	125	60	95	1.3	110	16	8-M8×1.25	6.2
45	12×3.3	1.3
50	14×3.8	1.5	90	88	155	80	125	1.3	140	16	8-M8×1.25	9.5
55	16×4.3	1.5
60	18×4.4	1.5
65	18×4.4	1.8	105	103	175	95	145	1.3	162	16	8-M8×1.25	13.1
70	20×4.9	1.8
