API Standard F-1300,F-1600/1600L Mud Pump for Drill Rig
- Qingdao/Tianjin
- T/T PayPal
You May Like
Product Details
| Place of Origin | Shandong, China | Brand Name | Ruite | |
| Model Number | F800 mud pump | Structure | Piston Pump | |
| Usage | Oil | Power | Other | |
| Standard or Nonstandard | Standard | Fuel | Diesel | |
| Pressure | High Pressure | Application | Other, oilfield drill rig |
Product Description
Specifications
1.better price2.reliable quality
3.in-time after-service
4.quickly reaction
F-1300,F-1600/1600L TECHNICAL PARAMETERS
Strokes/ Minute | Liner Size,mm Pressure Rating,MPa(psi) | |||||||||||||||
| 180 | 170 | 160 | 150 | 140 | 130 | ||||||||||
F-1300 | 18.7 | 2720 | 21.0 | 3050 | 23.7 | 3440 | 27.0 | 3915 | 31.0 | 4495 | 34.5 | 5000 | ||||
F-1600/1600L | 23.6 | 3345 | 25.9 | 3750 | 29.2 | 4235 | 33.2 | 4820 | 35.1 | 5000 | 34.5 | 5000 | ||||
Power Rating | Displacement L/S(GPM) | |||||||||||||||
F-1300 | F-1600/1600L | |||||||||||||||
kW | HP | kW | HP | |||||||||||||
*120 | *969 | 1300 | 1193 | 1600 | 46.54 (737) | 41.51 (658) | 36.77 (583) | 32.32 (512) | 28.15 (446) | 24.27 (385) | ||||||
110 | 889 | 1192 | 1094 | 1467 | 42.66 (676) | 38.05 (603) | 33.71 (534) | 29.62 (469) | 25.81 (409) | 22.25 (352) | ||||||
100 | 808 | 1083 | 994 | 1323 | 38.78 (614) | 34.59 (548) | 30.64 (485) | 26.93 (427) | 23.46 (372) | 20.23 (320) | ||||||
90 | 727 | 975 | 895 | 1200 | 34.90 (553) | 31.13 (493) | 27.58 (437) | 24.24 (384) | 21.11 (334) | 18.21 (288) | ||||||
1 |
|
|
|
| 0.3878 (6.147) | 0.3459 (5.483) | 0.3064 (4.857) | 0.2693 (4.269) | 0.2346 (3.719) | 0.2023 (3.206) | ||||||
NOTE: 1.Based on 100% volumetric efficiency and 90% mechanical efficiency.
2.*Recommended strokes and input power for continuous service.
wooden box via sea
fessional technology
2.after sales
3.good warranty
4.quickly reaction
Shengli Oil Field Ruite Machinery Manufacturing Co., Ltd. is fastly developing oilfield equipment and serivice company,With outstanding quality products and customer service, we have customers from North America, South America, Russia, Kazakhstan and so on. We are looking forward to establishing business relationship with customers around the world!
Contact:
Paul Lu
Sales Manager
Shengli Oil Field Ruite Machinery Manufacturing Co., Ltd.
ADD:No. 188, Road 14, Shengli Economic Development Zone, Dongying, Shandong,China
Tel:+86-546-7766658 Fax:+86-546-7077866
Mob.&Whatsapp:0086-13285312706
Email:paul(at)
Skype:lu126556
