Help CenterAPI 5CT Tubing Pipe Drill Pipe Steel Tube Casing Pipe for Water Well Drilling Oil Pipe
Related Products
-
Oilfield Equipment API Standard Non Magnetic Drill Collar High Quality ManufactureUS$ 1 - 1,000MOQ: 1 Piece -
Oilfield Equipment Drill Pipe Spinner Kelly Drill Pipe Spinner ManufacturerUS$ 1 - 1,000MOQ: 1 Piece
-
ERW Casing Pipe Steel Galvanized Pipe API 5L Oilfield PipeUS$ 1 - 1,000MOQ: 1 Piece
-
Epoxy Powder Coating 3 Anti-corrosion Tubing 2 7/8 Oilfield Tubing PipeUS$ 1 - 1,000MOQ: 1 Piece
-
Tubing Pipe API 5CT Standard Oilfield Pipe Oilfield Equipment Tubing Premium ThreadUS$ 1 - 1,000MOQ: 1 Piece
Specifications
1. API standard.2. ISO certificate.
3. Register with Sinopec.
4. Technical service.
5. Professional service for export.
Description
Material : J55 and N80 steel grade, non upset and external upset.
Size: 1.9 ", 2 -, 2-3/8 "7/8", 3-1/2 ",
Description: left-handed ground lines, a total of more than ten varieties.
Anticorrosion tubing is one kind of products treated on the basis of ordinary tubing, mainly used in injection Wells, well acidification, H2S containing oil and gas Wells and serious oil, wax precipitation well structure, etc. Our products have the performance of anti-corrosion,good abrasion resistance, fatigue resistance and excellent corrosion resistance, and does not pollute the environment, long life service etc.
Main products standard:
SY/T 0442-0442 "steel pipeline welding epoxy powder coating technology standard".
The API SPEC 5CT “casing and tubing specification”
The API SPEC 5B of the casing, tubing and line pipe thread processing, measurement and inspection specification".
Finished product were consisted of tubing body and coupling, epoxy powder coating and a thread protector. Both ends of the pipe body and coupling have TBG tubing round thread processing, coupling, in accordance with the recommended tightening torque machine is tight on the pipe body .
Technical Parameters of Anti-corrosive Tubing Internally Coated Epoxy Power
|
No. |
Specs |
Tubing Parameters |
Coating Parameters |
||||||
OD of body |
Wall Thickness |
Type of |
Shock Strength |
Abrasion |
Adhesion |
Pin-hole |
Coating |
||
mm |
mm |
||||||||
1 |
1.9 |
48.26 |
3.68 |
NU or EU |
≥11J |
≤20mg |
1-3 |
≤1 |
250~300μm |
2 |
2-3/8 |
60.32 |
4.83 |
||||||
3 |
2-7/8 |
73.02 |
5.51 |
||||||
4 |
3-1/2 |
88.90 |
6.45 |
||||||
5 |
4 |
101.6 |
5.74 |
NU |
|||||
6.65 |
EU |
||||||||
6 |
4-1/2 |
114.3 |
6.88 |
NU or EU |
|||||
