wood pellet press machine from China

Specifications

wood pellet press
1. Low price
2. High quality, high density
3. CE&ISO9001
4. Structure closely

Forage pellet making machine :



This machine is mainly applied to granulation. Such as sawdust, rice husk, cotton stalk, cotton seed skins, rice husk, peanut shell, bamboo, empty fruit branch, weeds and crop stalks and other plant waste can also be applied to lio-fertilizer, organic manure, fertilizer, such as low-temperature granulation.



It has been installed with the electrical control box. Also making the oil cake for the feedstuff ,which it could be granule /pellet for the fish, chicken, animal, etc. In Africa, it is used for making the cassava pellet for the food.



Advantages of our products is structure closely, easy to use, run stably, Advantages of pellets is high density, high fuel value, low moisture and low ash content. Gearbox of pellet mills running by high precision gears, Auto-matic Lubricant pump working between gearbox and main shaft bearing. To guarantee the bearing long life.



The final size is Diameter 6,8,10,12mm for the sawdust pellet , and 2mm, 4mm, 6mm, 8mm, 10mm, 12mm, etc. foranimals food.





Features:



1. Raw material moisture requirement is 10-15% before enter into Pellet Machine.



2. The diameter of pellet (final size ) could be 1.5mm-60mm, according to customer’s need.



3. The length of pellets can adjust by change cutter's position.



4. Widely use  to press fuel /feed/fertilizer pellets.



Technical data:



Model	Power(kw)	Capacity(kg/h)	Dimension(mm)	Weight(kg)
SKJ350	30	400-500	1650*700*1300	1000
SKJ450	37	600-700	1300*700*1500	1450
SKJ550	45	800-1000	1400*750*1600	2000
SKJ800	90	1500-2000	1900*1000*2000	3900
SKJ1000	110	2500-3000	2000*1000*2050	4800
