Stable Performance Wood Pellet Feeder

Stable Performance Wood Pellet Feeder photo-1
US$ 1,000 - 8,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Production Capacity:
4ton/h
Motor Type:
AC Motor
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Production Capacity 4ton/h
Motor Type AC Motor
Power(W) 7.5kw
Place of Origin Henan, China
Brand Name Telon
Model Number TL-360
Dimension(L*W*H) 1460*1460*2040mm
Certification CE,ISO
Warranty 1 Year
After-sales Service Provided Engineers available to service machinery overseas

Introduction of wood pellet feeder

Briquette press machine is the main equipment to make stick solid fuel with such wood material as bits of wood, rice shell or peanuts shell, etc. The raw material(12% Water proportion) dried by the dryer(12% humidity)will be formed into fuel under high pressure and at high temperature.



Working principle of wood pellet feeder

This series of  charcoal briquette press machine will pass the power on to the two pressure roller through the reducer.The two sides and roll rotation, in both the rotating roll,Natural materials to enter the ball roll mode, with the roll rotation, material pressure on a small become larger, When the material to the two rollers rotating line contact point, the pressure of materials has reached the peak. Tremendous pressure in the role of line, the materials become a finished product from the powder ball.

Pictures of wood pellet feeder

Stable performance wood pellet feeder



Stable performance wood pellet feeder



Finished Product

Stable performance wood pellet feeder Stable performance wood pellet feeder

Stable performance wood pellet feederStable performance wood pellet feeder



Mainly parameter of wood pellet feeder

Type

Dia of roll

(mm)

Capacity(T/H)

Power(KW)

Overall size

(mm)

Reduction type

Weight

(T)

360

Φ360

4

7.5

1460×1460×2040

400

1.4

400

Φ400

6

11

2450×1600×2230

500

2

500

Φ500

10

22

2650×1750×2300

500

2.6

650

Φ650

14

37

2880×2220×2500

650

5.5

750

Φ756

17

45

3015×2441×2166

750

7

800

Φ804

20

55

3200×2550×2220

850

8

1000

Φ1000

30

90

2600×3000×2500

1300

25

Shipping of wood pellet feeder





How to choose a suitable briquette presss machine



1. What’s the raw material?



As different materials match different machines, So pls tell us what’s the raw material.



2. The moisture of raw material ?



The moisture determines whether dryer is needed in the process.



3. The size of raw material ?



It should be crushed if the size is too big.



4. Capacity you need ?



Different capacity match different models of machine. the smaller the capacity is, the simpler the process will be.
