Beat Sale Wire Drawing Machine

Beat Sale Wire Drawing Machine photo-1
Beat Sale Wire Drawing Machine photo-2
US$ 200,000 - 200,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Inlet Diameter:
5.5mm
Outlet Diameter:
2.0mm
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao & Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Inlet Diameter 5.5mm
Outlet Diameter 2.0mm
Place of Origin Henan, China
Brand Name Telon
Model Number LW
Voltage 380V
Power(W) 18.5-30kw
Dimension(L*W*H) 1700*1150*1750
Weight 2000kg
Certification CE ISO9001
Warranty 1 Year
After-sales Service Provided Engineers available to service machinery overseas
Packaging & Shipping

 Beat Sale Wire Drawing MachineBeat Sale Wire Drawing Machine

Product Description

 This Kind of machines ( pulley or OTO type ) is an ideal equipment used to draw steel wire material of high, medium and low carbon steel , as well as copper,alumium and alloy, the machines are applied to drawing wire in the factories and nail, screw and rivet making factories etc.

Main technical param



Item

unit

           Continuous Multi-block Type

Model



LW- n/ 560

LW-n/450

LW-n/350

Max. drawing pass (n)



 n: 1 - 10

 n: 1 – 8

n: 1- 8

Tensile strength of wire rod

Kg/mm2

>110

128

>140

max dia. of wire rod

mm

6.5

3.4

2.5

min dia. of finished wire

mm

2.5

1

0.75

Typical configuration

--

LW1- 6/560

LW1-7/450

LW1-6/350

max average reduction percent

%

30

20

21

designed total reduction percent

%

78-88.5

77.9

78

Max. speed of block

m/min

245 (block. 6)

346.9 (block. 7)

200 (block 6)

Total power

kw

18.5-30

7.5-11

7.5-11

weight

kg

2000

1500

1000

Overall dimensions

mm

1700x1150x1750

1520x810x1700

1400x800x1500

Company Information

 Gongyi city telon industry and trade co., LTD., founded in 1998, is located in gongyi city, henan province is an export enterprise in China.We won the excellent prize of scientific and technological achievements in zhengzhou and consecutive years awarded the honorary title. As an entity enterprise.
