Simple discription of sawdust charcoal briquetting machinery:
1.Good quality sawdust charcoal briquetting machinery;
2.2 patents
2.High capacity and density
3.High wearable degree
4.Low consumption.
Usage of sawdust charcoal briquetting machinery:
This machine can take sawdust, wood, rice husk, coconut shell, peanut shell and other woody materials into briquette, which can be used for bioler, heating and warming and making charcoals.
Working Priciple of sawdust charcoal briquetting machinery:
Briquetting is a process that biomass is compressed under high pressure and high temperature.
The lignin content that occurs naturally in biomass is liberated under high pressure and temperature. Lignin serves as the glue in the briquetting process, thus binding, compressing the biomass to form into high density briquettes.
During this process, no binder needs to be used. So the output briquette is a type of clean and green fuel that is ideal for use in furnaces, boilers and open fires. The density of the briquettes is 900-1400kg/m2.
Sawdust charcoal briquetting machinery:
1.Our sawdust charcoal briquetting machinery awarded 2 patents ( patent number: 200530100650.5, 200520031212.2).
2.The sawdust charcoal briquetting machinery shows the features of big capacity, low energy consumption, compact and durable.
3.Many performance data of sawdust charcoal briquetting machinery such as capacity, coal bar density, electric consumption and wearable degree have reached advanced level.
4.Our newly developed sawdust charcoal briquetting machinery can be used as charcoal powder shaping machine by replacement of some spare parts
It is the necessary machine for making charcoal, and the working process of making charcoal is:
Data of this kind of sawdust charcoal briquetting machinery:
Type |
Power |
Output |
Inlet particle size |
Dimension |
Material humidity |
TL-III |
11kw |
90-110kg/h |
≤5mm |
1.67*0.68*1.55m |
≤12% |
TL-IV |
15kw |
120-140kg/h |
≤5mm |
1.65*0.6*1.6m |
|
TL-V |
18.5kw |
190-220kg/h |
≤5mm |
1.65*0.6*1.6m |
|
TL-VI |
22kw |
280-300kg/h |
≤5mm |
1.65*0.6*1.6m |
Easy wear parts of sawdust charcoal briquetting machinery:
