4 Ton Wood Grasper Loader With 129kW DEUTZ Engine and Joystick Pilot Control

Name: 4 Ton Wood Grasper Loader With 129kW DEUTZ Engine and Joystick Pilot Control
Brand: ANSION
SKU: 140141116
Availability: InStock

Qingzhou Ansion Machinery Co., Ltd.

US$ 25,500 - 30,000 MOQ: 1 Set

Key Specifications

Condition:

New

Brand Name:

ANSION

Model Number:

LW400KN

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao Port China

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Brand Name ANSION

Model Number LW400KN

Place of Origin Shandong, China

Type Front Loader

Moving Type Wheel Loader

Dimension(Long * Breadth * High) 7017 x 2500 x 3340 mm

Rated Load 4 ton

Certification ISO9001

Warranty 12 months

After-sales Service Provided No overseas service provided

ANSION brand new 4 ton Wood Grasper Loader

Standard with wood grasper loader
125kW (170HP) WEICHAI DEUTZ diesel turbocharged water-cooled engine [ CUMMINS optional ]
20.5-25 tires & 4x4 heavy-duty driving axles
Hydraulic pilot control by one joystick
12 ton operating weight

Product Description

Model		ZL40F
Working performance	Rated load	4000 kg
	Bucket capacity	4 ton wood grasper loader
	Working device	Quick hitch, pallet fork, wood grapple, dozer blade, 4-in-1 multifunction bucket, road sweeper, snow blower , enlarged bucket, rock bucket
	Dumping height	3200 mm
	Bucket auto leveling system	Yes
	Breakout force	127 kN
	Total cycling time	9.15 s
Overall performance	Overall dimension	7017 x 2500 x 3340 mm
	Operating weight	11800 kg
	Operating type	Mechanical / Pilot control
	Fuel tank	156 L
Engine	Engine model	WEICHAI DEUTZ / CUMMINS
	Type	Turbocharged, water cooled, 6 cylinders
	Rated power	129 kW (170HP)
Steering system	Steering	Articulating hydraulic
Steering system	Turning radius	6400 mm
Transmission	Gear box	Countershaft powershift
	Gear shift	Forward 4 and reverse 2
	Axles	Dry type and 4x4 driving
	Service Brake	Air over hydraulic caliper
	Parking brake	manual
	Tyre	20.5-25
	Max.travel speed	40 km/h
	Tractive Force	97 kN

Production & Loading

Workshop for wheel loader and backhoe loader manufacturing
As a professional manufacturer and trading combined factory , specialized in the export of wheel loader, backhoe loader, motor grader ,forklift and all kinds of attachments, with 25 years of experiences,
