ANSION 4x4 backhoe loader AS790
1) 1.5 m3 large loading bucket with 3500 mm dumping height
2) 0.3 m3 excavatoring bucket with 4000 mm digging depth (5000 mm is optional with telescopic boom)
3) CUMMINS 75kW diesel engine or YUCHAI 83 kW diesel engine
4) 4x4 driving axles with large tractive force
5) Cabin with air conditioner and pilot joystick control
6) Standard with quick coupler for All kinds of attachments such as fork, grapple, snow blade , hammer etc.
Backhoe loader | WZ30-25 (AS790) |
Overall dimension (L*W*H) | 7145 * 2300 * 3355 mm |
Total weight | 7900 kg |
Backhoe performance |
|
Digging bucket capacity | 0.3 m3 |
Max. Digging depth | 4016 mm |
Max. Digging height | 5330 mm |
Max. Digging radius | 5140 mm |
Boom rotary angle | 190° |
Loader performance |
|
Loading bucket capacity | 1.3 - 1.5 m3 |
Max. Lifting height | 4950 mm |
Max. Dump height | 3500 mm |
Max. Dump distance | 1105 mm |
Rated load capacity | 2500 kg |
Boom lifting time | 3.5 s |
Boom falling time | 2.5 s |
Total cycling time | 7 s |
Engine |
|
Model | YUCHAI 4105 (Turbocharged) CUMMINS 4BT3.9-C100 |
Rated power | 85 kW |
Max. Flow | 63 m/r |
Working pressure | 18~20 MPa |
Transmission |
|
Grade ability | 30% |
Turning radius | 5200 mm |
Gear shift | Forward 4 and reverse 4 (with mechanical high/low speed) |
Travel speed | 38 km/h |
Min. Ground clearance | 320 mm |
Tire | 16/70-20 |
