Specifications
China Hammer stone cutting machines with good priceUsed for crushing various mid-hard
Famous Brand
ISO9001-2008
Seal body
[Feed size]: 350mm
[Capacity]: 5-150m ³ / h
[Applications]: Hammer crusher for crushing various mid-hard and abrasive weak materials, compressive strength of the material does not exceed 100MPa, moisture content less than 15%.
Material to be broken coal, salt, chalk, gypsum, brick, limestone, etc., are also used for crushing fiber structure, strong flexibility and toughness of broken wood, paper or broken asbestos cement waste to recycle asbestos fibers and so on.
[Products]: Hammer crusher can be divided into single rotor (single-axis) and the double rotor (biaxial) two. Single-rotor type can be divided into irreversible and reversible two. If the hammer Rows by how many points, can be divided into single-row and multi-row style.
Purpose and scope:
Hammer crusher is directly 600-1800 mm maximum particle size of the material crushed to a period of 25 or 25 mm below the crusher crusher.
Hammer crusher for cement, chemical, electric power, metallurgy and other industrial sectors crushing medium hardness materials, such as limestone, slag, coke, coal and other materials in the debris and crushing operations.
Working principle:
The motor drives the rotor rotates at high speed in the crushing cavity.
Material from the upper mouth to feed into the machine, hit, impact, shear, abrasive and high-speed movement of the hammer and smash.
In the lower part of the rotor, with sieve, sieve size of the crushed material is less than the grain size is discharged through the sieve, sieve size larger than the coarse fraction retained on the sieve and grinding continued to hit the hammer, and finally discharged through the sieve outside the machine.
Structural features:
Hammer crusher chassis body, rotor, hammer, back liner, sieve and other components.
Property Features:
1, working hammer, new technology casting, with wear and impact resistance characteristics.
2, according to customer requirements, adjusting the particle size desired.
3, the hammer broke the seal body structure to solve the crushing plant dust pollution and dust leakage problems.
4, the overall design is handsome in appearance, compact structure, less wearing parts, easy maintenance, etc., is the upgrading of products.
Technical Parameters:
Export standard, nude packing in container. Or wooden case if needed.
1. Have many years of production experience.
2. Price is better, can control the quality and delivery time.
3. Professional engineers for your design, drawing, ensure the quality of production if non-standard products.
4. The photos and films of prosuction process will be reported to you.
5. The Warranty period is 12 months.
1. Payment Term: 30% TT in advance+70% balance before shipment or total advance.
2. The remitter is responsible for the remittance charge.
3. The working time is about 20 working days from receive payment.
