Help CenterCheap Price LHW-101 2wd 12hp Hand Tractor With Tiller
Related Products
-
China Hand Start Condensational Hand TractorUS$ 500 - 600MOQ: 1 Set -
Country 12hp Manual Walking TractorUS$ 405 - 600MOQ: 1 Set
-
For Farm Work Manual Start Mini Walking TractorUS$ 405 - 600MOQ: 1 Set
-
8hp for Paddyfield 2wd Mini TractorUS$ 800 - 1,000MOQ: 5 Sets
-
8hp 10hp 12hp MIni TractorUS$ 498 - 980MOQ: 5 Sets
We also supply OEM service.
we would like to supply the suitable tractors according to your detailed requirement.
Chassis Information of LHW mini hand tractor | ||
Model |
GH-101-1 |
|
Overall Dimensions:(L×W×H) |
2150×980×1240mm |
|
Wheel tread |
Rubber wheel: 570-810mm; Iron wheel: 850-1090mm |
|
Tyre Size |
Front 6.00-12 (rubber); Rear 4.00-8 (rubber) |
|
Ground clearance |
210mm |
|
Net Weight (without rotary tiller) |
280 kg |
|
Net Weight (with rotary tiller) |
380 kg |
|
Working weight (with rotary tiller) |
430 kg |
|
Tyre Inflation Pressure(kg/cm²) |
For Cultivation 1.1~1.4 |
|
For Carrying 1.8~2.0 | ||
Speed (km/hr) |
Forward 1.39, 2.47, 4.15, 5.14, 9.12, 15.30 |
|
Reverse 1.10, 4.10 | ||
Rotary tiller |
Blades number: 18 |
|
Width 600 mm | ||
Turning Speed: 1st: Low:220, High:251 2nd: Low:233 High:291 | ||
Blades: 2 sets (1 for dry&1 for wet land cultivation) | ||
Engine Information | ||
Model |
ZH195N Diesel |
|
Type |
Single cylinder,4-stroke,horixontal,water-cooled,direct injection |
|
Cooling System |
Condenser (Radiator, made by brass metal) |
|
Rated power |
15HP(11KW) |
|
Rated speed |
2000rpm |
|
Fuel Tank Capacity |
9 kg |
|
Fuel Consumption (g/kw.hr) |
≤258.4 |
|
Structure Weight (kg) |
150 |
|
Engine Oil Sump (kg) |
2.5 |
|
Air Cleaner |
Oil Bath Type |
|
Fuel filter |
Duel Fuel Filter(Primary and Secondary) for controlling fuel adulteration |
|
Starting system |
Manual Cranking Type |
|
Clutch |
Multiple Dry Plate, Friction Type |
|
Lubricating way |
Combine pressure and splashing |
|
Other technical data | ||
Gear Box |
Six Speed Forward, Two Speed Reverse |
|
Main Frame Implements |
1) Anti-skid steel wheel(with 10 sprockets and extra bit) – 1 set |
|
2) 1 nos. rear iron wheel for mud cultivation | ||
3) Rotary blades 2 sets (1 for dry&1 for wet land cultivation) | ||
Clutch |
Double friction flat of constant combination |
|
Brake System |
Drum Type |
|
Accessories |
1 set tools and 1 set fast moving spare parts |
|
MOQ |
1units |
|
| ||
OEM service and multi option for you
1. 18 months warranty since machine arrives destination port
2. The spare parts:
(1) We will send you the tool box for free.
(2) For the vulnerable parts, we can send you for free, During the warranty, owing to the quality problem, we will send the replacement for free.
3. T/T (Telegraphic transfer) payment: 30% as deposit, 70% balance payment shall be paid before delivery
4. delivery time: 20 working days after confirmation of deposit
5. Loading: LCL in iron crate or wooden case
we would like to try our best to help you to choose the suitable type!
