Portable Emergency Ventilator ACM812A

Specifications

ACM812AVentilator

1. Suitable for adult and child

2. For various treatment environments such as emergency room, operating theater, ambulance, patient transfer and first-aid

3. Unique invasive and non-invasive ventilation modes to meet the different patients’ needs

4. Inspiration halt, convenient for sucking phlegm

5. Oxygen mixing technique to adjust oxygen concentration and meet the oxygen therapy need

6. Alarm and monitoring system which meet the international safety standard

7.TFT screen, displaying various respiration parameters and waveforms

8.With built-in battery and on-vehicle power connector for A/C and D/C power supply

9.PEEP valve, humidifier, trolley, supporting arm and other accessories as optional

Main parameters

Applications                                                                                 Adult, child

Control mode                                                                              Pneumatic driven and electric controlled, time switch, pressure                                                                                                                  limit, volume control, apnea ventilation

Ventilation modes                                                                      A/C, SIMV, SPONT, SIGH, NIPPV, manual

Respiratory rate                                                                          4bpm~80bpm

Tidal volume                                                                               0,50ml~1500ml

I:E ratio                                                                                         1: 0.3, 1: 0.5, 1: 0.7, 1: 1, 1: 1.5, 1: 2, 1: 2.5, 1: 3, 1: 3.5, 1: 4

Trigger sensitivity                                                                       -2kPa~2kPa,continuously adjustable

Oxygen concentration                                                               48-100%

Display mode                                                                              LCD screen display

Waveform                                                                                    Airway pressure waveform display

Alarm parameters

Upper airway pressure limit Lower airway pressure limit

Low battery alarm

Power supply failure

Silence for alarm
