540TVL CCD Mini Secret CCTV Small Hidden Camera

540TVL CCD Mini Secret CCTV Small Hidden Camera photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Correa
Model Number:
CS3120CH
Payment & Shipping
Payment Methods:
Port of Shipment:
HongKong
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Guangdong, China
Brand Name Correa
Model Number CS3120CH
Type Digital Camera
Style Mini Camera
Sensor CCD
Technology Other, 2-boards
Special Features Other, Pinhole lens, wide angle lens and vari-focal lens Optional

Specifications

540TVL CCD Mini Secret CCTV Small Hidden Camera
1. High resolution and good image
2. Tiny size


540TVL CCD Mini Secret CCTV Small Hidden Camera









Mini high resolution camera, this is a new variable voltage CCD video camera, it runs at a 540TVL high resolution and very good quality performance. The benefit is the convenience of the DC 5-15V power range.


Fetures:

* 1/3 Sony super HAD CCD

* 540TV Lines, 0.05Lux,

* Mini size : 20x20mm , two boards

* Good image in low light conditions


Low Current Frequency , only 50mA, solve the hot problem ,nice back light compensation, used for the ATM surveillance or under sharp contrast in lighting conditions.





 Spec.:

Model No.
CS3120CH (3.6mm board lens)
Image Device
1/3" Sony Super HAD II Color CCD
Horizontal Resolution
540 TVL
Minimum Illumination
0.01 lux
Number of Pixels
PAL : 752(H) x 582(V), NTSC :768(H) x 492(V)
Scanning System
PAL: 625 Lines, 50 Field/Sec; NTSC: 525 Lines, 60 Field/Sec
Sync System
Internal Synchronization
Video output
1Vp-p 75 Oms , Negative
White Balance
Auto
S/N Ratio
More Than 48dB (AGC off)
Gamma Characteristic
0.45
Electronic Shutter
PAL : 1/50~1/100,000 Sec; NTSC : 1/60~1/100,000 Sec, auto
Lens
3.6mm wide angle lens
Power Consumption
DC 5-15V, 50mA
Operation Temperature
-10°C ~ + 50°C, RH 95% Max
Storage Temperature
-20°C ~ + 60°C, RH 95% Max
Housing
Black
Dimension
20x20mm,2-boards



Our Workshop:
