Help CenterBuilding Material Oil Cooling Electromagnetic Separator of Good Performance
Related Products
-
Air Cooling Cross Conveyor Belt Electric Magnetic SeparatorUS$ 2,000 - 200,000MOQ: 1 Set -
Highly Effective Pet Bottle Flakes Containing Aluminum SeparatorUS$ 2,000 - 400,000MOQ: 1 Set
-
Box-type Grille De-ironing Separator of High Power MagnetsUS$ 2,000 - 200,000MOQ: 1 Set
-
Aluminum Separator for Papermaking WasteUS$ 2,000 - 200,000MOQ: 1 Set
-
Vertical Ring and Pulsating High Gradient Magnetic SeparatorUS$ 2,000 - 200,000MOQ: 1 Set
It is widely arranged in the lines such as coal, port, thermal generate-power, cement, building material and so on.
Standard Features and Benefits:
1. With the computer-simulating design of magnetic circuits, it has deep magnetic depth and high magnetic field intensity.
2. With special design of exciting coils, it has longitudinal and latitude cooling oil paths. The heat can be easily transformed to the cooling oil to lower the coil temperature.
3. The special designed wholly sealed coils are moisture-proof, dustproof and corrosion prevention.
4. The corrugated heat-releasing wings enlarge the cooling area and effectively control the temperature rise.
5. Easy maintenance, self-clean iron wastes, robust performance.
6. The waist-drum shape roller can rectify the belt automatically. With the wholly sealed bearing blocks, it can achieve trouble-free operation for a very long time.
7. With near and remote control system, it has a wide application.
Models |
Conveyor Belt Width |
Rated Lifting Height |
Magnetic intensity |
Exiting Power |
Cooling Type |
Appearance Measurement(mm) |
weight |
||
mm |
mm |
Gs |
Kw |
L |
W |
H |
Kg |
||
RCDE-6 |
650 |
200 |
≥700 |
≤5 |
coil cooled |
1050 |
1005 |
905 |
810 |
RCDE-8 |
800 |
250 |
≥700 |
≤6 |
1170 |
1050 |
1070 |
1150 |
|
RCDE-10 |
1000 |
300 |
≥700 |
≤9 |
1213 |
1135 |
1190 |
2080 |
|
RCDE-12 |
1200 |
350 |
≥700 |
≤10 |
1510 |
1400 |
1260 |
2980 |
|
RCDE-14 |
1400 |
400 |
≥700 |
≤11 |
1700 |
1610 |
1350 |
3570 |
|
RCDE-16 |
1600 |
450 |
≥700 |
≤12 |
1910 |
1730 |
1420 |
5540 |
|
1. Packing: Export packing
2. Shipping time: 30 days after receive the deposit
With well-equipped professional engineers and strong technical ability, our company has been in this field for 10 years.
1.We cooperate with superior suppliers (Nord &Schneider)to ensure the quality.
2.Tests of materials are freely checked for the required quality of the equipment before packing.
3.Engineers are always available to service for machinery commissioning overseas, which is not only after sales service support, but also technology support .
4."Keep Improving, Pursuing Excellence" would be kept forever.
1. What is the MOQ of your machine?
A: Our MOQ is 1 set
2. How long is the machine warranty period?
A: The product warranty period is 12 months
