digital rpm measuring instrument meter BC-GT33
BC-GT33 is a small and light module with low price used for checking and demonstrationg RPM,Frequency and Accumulation hours of the genset. The switch on its back can adjust and set parameters in order to meet different requests from users. Besides, it uses the European-style teminals for connection which is more convenient for installation and detachment.
Main Features:
- ØLED circuit can demonstrate rough RPM
- Ø4-digital tube can demonstrate RPM,Frequency and Accumulating Hours (Optional)
- ØThree double-color LED display;
- ØFlywheel theeth and alarm value settings through Buttons;
- ØRPM,Frequency can be switched.
- ØOver-speed Alarm output and demonstration.
- ØDial switch setting and parameters modification.
Parameter
- ØEngine RPM
- ØGenerator Frequency
- ØHours
Range and Accuracy
- ØRPM:0-3000RPM(RPM/min),RANK:1.0
Specification
- ØPower:DC 8~36V
- ØConsumption Power: MAX:1 W
- ØOperation Temperature:-20℃~ 65℃
- ØSize(W * H * D):78mm * 75mm * 76mm
- ØInstallation Size(W * H):67mm * 67mm
- ØNet Weight: 110G
Advantages:
1, Attractive appearance, innovative features, digital and bar-graph display;
2, Accurate measurement,through the LED displays AC current, Voltage, Frequency,Current working time and Accumulating time;
3, Lower price, save nearly half the cost than the old mechanical meter;
4, With over-voltage, under-voltage electricity, over-current, over frequency, low frequency protection function;
5, Through setting can be adapted to various power , various brands of engines.
More Products we supply:
Other Models you may be interested in :
BC-GV13R |
AC voltage/frequency/running hours (hours calculated each time, datas cleared once shutdown) |
BC-GV13F |
AC frequency |
BC-GV13V |
Voltage (single phase) |
BC-GV13H |
Hour Meter |
BC-GV23 |
AC voltage/frequency/Current |
BC-GV23F |
AC Frequency |
BC-GV23V |
AC Voltage(single phase) |
BC-GV23A |
AC Current (single phase) |
BC-GV23VH |
AC voltage/frequency/running hours |
BC-GV23VS |
voltage (single phase) with protections of over/under voltage. output can be off,10A |
BC-GV23AT |
Three phases Current Meter |
BC-GV24 |
AC voltage/4-digital current/frequency/running hours (4 in 1) |
BC-GV25 |
AC voltage/current/frequency/power/power ratio COS (5 in 1) |
BC-GT30 |
digital display RPM meter |
BC-GM40 |
oil pressure/oil temperature/water temperature/ voltage (4 in 1) |
BC-GM40H |
|
BC-GV50 |
Voltage/current/frequency(3 phases) with protections |
