25mm Inner Diameter Bearing CSK25 Dealer

25mm Inner Diameter Bearing CSK25 Dealer thumbnail-1
25mm Inner Diameter Bearing CSK25 Dealer thumbnail-2
25mm Inner Diameter Bearing CSK25 Dealer thumbnail-3
25mm Inner Diameter Bearing CSK25 Dealer thumbnail-4
25mm Inner Diameter Bearing CSK25 Dealer thumbnail-5
25mm Inner Diameter Bearing CSK25 Dealer thumbnail-6
25mm Inner Diameter Bearing CSK25 Dealer photo-1
25mm Inner Diameter Bearing CSK25 Dealer photo-2
25mm Inner Diameter Bearing CSK25 Dealer photo-3
25mm Inner Diameter Bearing CSK25 Dealer photo-4
25mm Inner Diameter Bearing CSK25 Dealer photo-5
25mm Inner Diameter Bearing CSK25 Dealer photo-6
US$ 2 - 7.34 MOQ: 100 Pieces
Key Specifications
Get Latest Price
Brand Name:
CLUNT
Bore Size:
25,
Outside Diameter:
52,
Contact Supplier Request Quote Chat Now
Jinan Kelunte Bearing Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name CLUNT
Bore Size 25,
Outside Diameter 52,
Model Number CSK25
Precision Rating P0 P6 P5 P4
Seals Type OPEN RS 2RS RZ Z ZZ
Number of Row Single Row
Place of Origin Shandong, China

25mm inner diameter bearing CSK25 dealer

Product Description

25mm inner diameter bearing CSK25 dealer

Drawings of bearing CSK25

25mm inner diameter bearing CSK25 dealer







Quick Details of bearing CSK25

Product Model:  CSK25(6205)
Structure: Deep grove ball bearing
Rolling Element: Ball
Inside Diameter (ID): 25 mm
Outside Diameter (OD): 52 mm
Width(C): 15 mm/inch
Torque Rating (N.m):  68
Load (N) Dynamic:10.7
Load (N) Static:5.46
Weight: 0.14kg
Seals Type: ZZ, 2RS
Material: Gcr15
Cage Material: TN
Number of Row: Single
Precision Rating: P0 P6
Clearance: C2, C3, C4
Vibration acceleration: V1, V3
Bearing Noise:Z1, Z2


Dimension(in./mm) Torque N.m
d D W
.98/25 2.05/52 .59/15 68



Bearing Name CSK25
New Model CSK25
Old Model CSK25
product Model CSK25
Category
Brand bearings Bearing
Inner Diameter d ( mm ) 25
Outer Diameter D ( mm ) 52
Thickness B ( mm ) 15



Bearing NO./DTB Main dimensions(mm) Mass weight(kg) price (USD $ FOB)
d D B   P PP
CSK25(6205) 25 52 15 0.14 2.00 2.23 2.46





Descriptions of bearing CSK25

1) CSK  bearing type: CSK25P, CSK25PP2) d 25, D 52, C 15, sprag type, one way clutch bearing3) Material: Chrome steel4) Shield/closure:  P, PP5)Precision : ABEC-1 (P0), ABEC-3 (P6),ABEC-5(P5)6) Vibration and Noise level :  V2, V1, Z1, Z2
7) Internal clearance: C0, C2, C38) Packing: industrial packing or individual box packing, carton, pallet
9) Brand: CLUNT, OEM  Features of CSK bearing:
1. CSK bearing is one way bearing with a sprag type.2. CSK bearing has CSK..P, CSK..PP series.3. CSK bearins series are composed of a 62 series ball bearing (except CSK8 and 40).4. CSK bearing or One-way bearings are widely used in mining /hydraulic / textile / printing / washing machines, conveyor systems and so on. 5. One way bearing (freewheel bearing) CSK series, HF, HFL, FCB, B200 series.6. One way clutch (overrunning clutch), GFR, MZ series.   Please contact me if you have any question or demand on bearings.

CSK one way bearing CSK25 ball bearings, self-aligning ball bearings, angular contact ball bearings, insert ball bearings, needle roller bearings, thrust ball bearings, cylindrical roller bearings, tapered roller bearings, spherical roller bearings, thrust roller bearings, self-aligning ball bearings, ceramic ball bearing, plastic ball bearing, conveyor bearings, skate wheel bearing, Joint bearings, Linear Bearings etc.



 Please contact me if you have any question or demand on bearings.  One way bearing CSK technical details,



One way clutch bearing CSK3000

Bearing model Overall dimension(mm) Rated Weight (KG) Application
DTB GERMANY JAPAN d D B torsion Tkn(N.m)
OW608 CSK8   8 22 9 2.5 0.015
OW6201 CSK12   12 32 10 7.5 0.04
OW6202 CSK15 BB15 15 35 11 13.5 0.05 Motor
OW6203 CSK17 BB17 17 40 12 24.5 0.07
OW6204 CSK20 BB20 20 47 14 40 0.11 Washing
OW6205 CSK25 BB25 25 52 15 68 0.14 machine
OW6206 CSK30 BB30 30 62 16 110 0.21
OW6207 CSK35 BB35 35 72 17 140 0.3 Printing machinery
OW6208 CSK40 BB40 40 80 22 260 0.5
OW6205-2RS     25 52 15 60 0.14 Electric
OW6006-2RS     30 55 14 60   roller
B205     23.622 52 25 80 0.45
UF20B     20 60 20 120   Textile machinery



CSK Series: This range of clutches can be used as freewheels and can be used in backstop, overrunning or indexing applications. Freewheel bearings are characterised by their ability to turn in one direction only and thus transmit torque whilst having a zero backlash They are supplied filled with grease and are low maintenance. The torque is transmitted on the inner and outer race by an interference fit into a rigid housing and onto a shaft. The tolerance for the housing fit is N6 and the tolerance for the shaft is n6. Operating temperature range: minus 40 deg F to plus 212 deg F or minus 40 deg C to plus 100 deg C
Benefits: Cost effective replacement clutch bearing, low maintenance



CSK Series (One-Way Bearing)
The CSK model freewheel is a sprag type clutch integrated into a 6200 series ball bearing (except sizes 8 and 40). It provides you with a one way clutch, and eliminates the need for a ball bearing. It gives a high degree of freewheeling accuracy while utilizing a minimum of space.

The CSK model freewheels can be used in backstop, overrunning or indexing applications.

The CSK model freewheels are available with bores to 40mm (1.57") and torque ratings to 384 lb. ft. They are supplied filled with grease and are maintenance free.



Pictures of product

 25mm inner diameter bearing CSK25 dealer25mm inner diameter bearing CSK25 dealer25mm inner diameter bearing CSK25 dealer25mm inner diameter bearing CSK25 dealer25mm inner diameter bearing CSK25 dealer25mm inner diameter bearing CSK25 dealer



Company Information

25mm inner diameter bearing CSK25 dealer25mm inner diameter bearing CSK25 dealer25mm inner diameter bearing CSK25 dealer

Packaging & Shipping

25mm inner diameter bearing CSK25 dealer

Our Services
We are 100% manufacture. We can supply you technical support.
We have strict quality control processes. We supply high quality bearings with fair price.
We accept small quantity.
We may supply other globle brand bearings and offer buyer labels.
We can manufacture any bearings according to customer's drawings
