Help CenterHigh Tech Foam Automatic Vacuum Block Molding Machine
Related Products
-
Certificated Eps Machines for Foam Insulated BlockUS$ 29,100 - 97,000MOQ: 1 Piece -
Compact Low Noise Eps Block Thermoforming MachineUS$ 29,100 - 97,000MOQ: 1 Piece
-
Regenerative Hot Sale Eps Block Thermoforming MachineUS$ 29,100 - 97,000MOQ: 1 Piece
-
Adjustable Foam Blocks Moulding Machine With VacuumUS$ 29,100 - 97,000MOQ: 1 Piece
-
Auto Air Cooling Block Molding MachineUS$ 29,100 - 97,000MOQ: 1 Piece
1.Pictures of Products
2.Features of Products
1.the machine uses PLC programmable controller and touch the man-machine interface control, automatic feeding, automatic control of feeding process, it has formed a complete guarantee automatic cycle of production equipment.
2.the machine uses high-quality square tube and welded steel and other groups, each template through heat treatment, after assembling small deformation, durable.
3.the machine uses unique and advanced domestic and EPS penetrate thermoforming process, with penetrating ability, good adhesion, good product quality, significant energy saving features.
4.this machine uses advanced processing technology and piping arrangements, while referring to the advantages of foreign board machine design unique structure, greatly improving production efficiency, but also make it in the domestic foam sheet production equipment to achieve a leading position, is an ideal and efficient production equipment.
5.the machine uses the control instruments, electrical, pneumatic components, valves and other fittings are domestic and foreign high-quality brand-name products, equipment positive rectangular, flat shape, reliable quality.
6.the machine uses hydraulic station centralized control, hydraulic single door, hydraulic ejection release and automatic locking mechanism, so as to ensure the smooth operation of the machine, reliable performance.
7.each piece of foam board production valve 4-8 minute cycle, high production efficiency. Automatic pneumatic feeding, vacuum-assisted feeding, fast.
8.The formulation of raw materials, particle diameter, specific gravity and the foaming agent content and other parameters, set up expert control system, the amount of steam and the heating temperature adaptive proportional servo regulation, improve the quality of products and the degree of automation equipment, simplifying operation ;
9.set up a communication interface, equipment operation and product quality remote control.
3.Technical Data of Products
| Item | Unit | SPCB301206 | |
| Mould Cavity Size | mm | 3400*1240*630 | |
| Block Size | mm | 3000*1200*600 | |
| Steam | Entry | mm | DN150 |
| Consumption | kg/cycle | 30-40 | |
| Pressure | Mpa | 0.6-1.8 | |
| Compressed Air | Entry | mm | DN50 |
| Consumption | m³/clcle | 1.2-1.8 | |
| Pressure | Mpa | 0.5-0.8 | |
| Vacuum Cooling Water | Entry | mm | DN40 |
| Consumption | m³/clcle | 0.3-0.5 | |
| Pressure | Mpa | 0.2-0.4 | |
| Dralnage | Vacuum Drain | mm | DN125 |
| Down Steam Vent | mm | DN150 | |
| Air Cooling Vent | mm | DN150 | |
| Capacity@15kg/m³ | min/cycle | 8 | |
| Connected Load/Power | kw | 19 | |
| Overall Dimension(L*W*H) | mm | 7200*4500*3000 | |
| Weight | kg | 7500 | |
4. Application of Products
5.More product to choose
6.Packing and Shipping
Packing: standard exporting package
Shipping port: shanghai/ningbo
7.EPS raw material quotation
Please click on more data
1.Company information
2.Why choose us?
1. Automatic product, High thermal efficiency, Low moisture content.
2. Little noise, Clamping force, High strength.
3. High production efficiency, High efficiency heat conduction.
4. High tensile strength, Long service life, High penetrating power.
5. Good adhesion, Use less gas, Rapid prototyping.
