Help CenterMine Jaw Crusher
Related Products
Application of Jaw Crusher:
MingLei is a trusted and reliable brand for its high quality and good manufacturing. It specializes in producing Jaw Crusher which is widely applied to crush high hardness, mid hardness and soft rocks and ores such as slag, construction materials, marble, etc. The pressure resistance strength is under 200Mpa, that is, suitable for primary crush. Each model has a large feed opening for its size and an ideal nip angle, giving smooth material flow, high reduction efficiency and high capacity. Their simple design conceals many advanced features that give easy operation, simple maintenance, long life and a low cost per ton.
The structure of Jaw Crusher:
The structure of Jaw Crusher includes Main Frame, Main Axle, Roller Bearings, Eccentric Shaft, Jaw Plates, Side Plates, Toggle Mechanism, Fly Wheels and Springs.
The Features of Jaw Crusher:
1. Jaw Crusher is of various types;
2. Jaw Crusher is suitable for crushing maximum, medium and minimum stones;
3. The operating principle of Jaw Crusher is easy to be operated;
4. The structure of Jaw Crusher is simple and it is easy to maintain;
Operating principle:
Jaw crusher uses motor as its power. Through the motor’s wheels, the eccentric shaft is driven by the triangle belt and slot wheel to make the movable jaw plate move by a regulated track. Therefore, the materials in the crushing cavity composed of fixed jaw plate, movable jaw plate and side-lee board can be crushed and discharged through the discharging opening.
Specifications of Jaw Crusher:
| Model | Size of Feeder Opening (mm) | Max. Feeding Size (mm) |
Capacity (t/h) |
Motor Power (KW) |
Overall Dimensions (mm) | Weight (t) |
| PE150×250 | 150×250 | 125 | 1-3 | 5.5 | 896×745×935 | 1.2 |
| PE250×400 | 400×250 | 210 | 5-20 | 15 | 1430×1310×1340 | 2.2 |
| PE400×600 | 600×400 | 350 | 15-50 | 37 | 1700×1732×1653 | 6.8 |
| PE600×900 | 900×600 | 480 | 45-110 | 75 | 2290×2206×2370 | 17 |
| PE900×1200 | 900×1200 | 750 | 90-220 | 110 | 3800×3166×3045 | 50 |
| PE500×750 | 500×750 | 425 | 15-65 | 55 | 2035×1921×2000 | 12 |
| PE750×1060 | 1060×750 | 630 | 105-195 | 110 | 2655×2302×3110 | 29 |
| PEX250×750 | 750×250 | 210 | 15-30 | 37 | 1667×1545×1020 | 5 |
| PEX250×1000 | 1000×250 | 210 | 15-50 | 37 | 1550×1964×1380 | 7 |
| PEX250×1200 | 1200×250 | 210 | 20-60 | 37 | 2192×1900×1950 | 8.5 |
