Help CenterChinese Fully-Automatic 300000m3/year AAC Block AAC Panel Cutting Machine
Related Products
-
AAC Light Weight Conrete Brick Machine (Newest Technology )US$ 700,000 - 1,100,000MOQ: 1 Set -
Strong Quality AAC Plant , Automatic System Control AAC Block Production LineUS$ 605,000 - 3,100,000MOQ: 1 Set
-
HF 300000m3 AAC Production Line, Aac Block Making Machine, AAC Cutting MachineryUS$ 605,000 - 3,100,000MOQ: 1 Set
-
AAC Autoclaved Aerated Concrete Block Production LineUS$ 605,000 - 3,100,000MOQ: 1 Set
-
Sand Aac Making Production Line Automatic Aac Block Machine Supplier Full Automation Aerated Block Production Line in IndonesiaUS$ 600,700 - 1,100,000MOQ: 1 Set
Specifications
Fully-Automatical 300000m3/year AAC Block AAC Panel Cutting Machine,the leader in China ,international quality ,65%market shareFully-Automatic 300000m3/year AAC Block AAC Panel Cutting Machine
------------new technology by Shandong Hongfa
Chinese Fully-Automatic 300000m3/year AAC Block AAC Panel Cutting Machine Chinese Fully-Automatic 300000m3/year AAC Block AAC Panel Cutting Machine
Chinese Fully-Automatic 300000m3/year AAC Block AAC Panel Cutting Machine
Process:
stocking raw materials →mixing → molding → forming → cutting → evaporating and curing → crane cramp → transporting etc.,
.introduction:
Areated concrete brick /panel is the light and porous buidling material. It has light weight keeping temperature cant burn and other advantages.it can be made into many kinds of bricks(for example:600×200×100,80×80×180,240×115×53,600×200×125),they could be used industry building and common building.they are more and more popular in the world.in the future,they will replace the Clay brick completely.
Areated concrete common conception:
Common concrete density is usually 1600-2400kg/m3,but Areated concrete are 500kg/m3,600kg/m3,700kg/m3.It has not the big grain,main use silicon material (for example:coal ash,sand,stone dust and others ),through making the material small for example sand,they can be used directly if has enough degree of small (for example coal ash.Mixing calcium material lime cement water to a special slop,then add the aluminum dust and the additive.Make the aluminum dust and the special slop have a Chemical reflect.then produce Hydrogen to make the concrete slop to expanding or swell,foam.Next,put them into the curing room to concreting cutting steaming curing,last,there will bacome the light brick,the porous rate is 70-80%.
Advantages of AAC making machine:
light weight
Areated concrete density is usually 400-700kg/m3,(according the market in produce ),same as 1/3 of clay brick and 1/5 common concrete.So use the Light brick can reduce the weight of the build more,and also reduce the beam of roof and pillar press best.then you can see,it can save the material and cost,it also fighting shaking.
keeping temperature
It has many porous,the delivery hearting coefficient is 0.9-0.22W/(mk),the same as 1/4 or 1/5 of clay brick,so it is best materials now in the world. Also many kinds raw material,have lowest wasteMain Material:coal ash sand waste mine material coal stone,stone dust and other silicon materials.
Material ratio:
1 Product weight is according to 600kg/m3 to control.
2 annual capacity 300,000M3.
3 set raw material proportion: cement 6.5%, raw lime 23%, flyash 68%, gypsum 3%, aluminum paste powder 350g/M3.
4 water and material rate 0.631
5 one mould product 2.88M3
6 Casting slurry cycle time 5-6 minutes, cut cycle time 5 minutes.
7 casting slurry temperature 38-42 degree
8 body quiet stop. Time is 1.5-2.5hours, temperature 50-90 degree, after quiet stop body strength is 0.15-0.18Mpa
9 Steam curing cycle time, come in and out autoclave about 0.5hour, steam curing cycle time about is 6 hours/1.6Mpa, total 6.5 hours.
10.Cement lime fly ash style aerated block raw material proportion
name |
unit |
Cement lime fly ash |
flash |
% |
65-70 |
cement |
% |
6-15 |
lime |
% |
18-25 |
gypsum |
% |
3-5 |
Aluminum powder paste(600kg/m3) |
1/10000 |
8 |
Water & material rate |
|
0.60-0.65 |
Casting system |
OC |
36-40 |
Aluminum mixing time |
S |
30-40 |
Reference: cement is 42.5 Portland or 42.5 common cement
Aluminum power paste calculate to use according to 600kg/m3
Remark: the accurate batching rate is adjustable according to the raw material locally
About Shandong Hongfa
We are the top leader in China on manufacturing the Autoclaved Aerated Concrete Line(AAC) with 65% market share.
We can supply our customer for designning, production, installation, commissioning, training and good after-sale service.
You can feel free to contact us for more information and any help ,it wil be our pleasure to be of service to you .
You can send me email .or call me at : 0086-13969983506
