Our company built in 1990, we have four factories in china ,our main products are AAC block plant ,concrete mixing plant , concrete block machine . we have pased ISO9001, CE, BV,SGS.
shandong capacity 200000m3/year AAC block making machine
1.AAC block production line , Autoclaved Aerated concrete block machine introduction
Areated concrete brick (light brick ) is the light and porous buidling material. It has light weight keeping temperature cant burn and other advantages.it can be made into many kinds of bricks(for example:600×200×100,80×80×180,240×115×53,600×200×125),they could be used industry building and common building.they are more and more popular in the world.in the future,they will replace the Clay brick completely.
2.AAC block production line , Autoclaved Areated concrete block machine common conception
Common concrete density is usually 1600-2400kg/m3,but Areated concrete are 500kg/m3,600kg/m3,700kg/m3.It has not the big grain,main use silicon material (for example:coal ash,sand,stone dust and others ),through making the material small for example sand,they can be used directly if has enough degree of small (for example coal ash.Mixing calcium material lime cement water to a special slop,then add the aluminum dust and the additive.Make the aluminum dust and the special slop have a Chemical reflect.then produce Hydrogen to make the concrete slop to expanding or swell,foam.Next,put them into the curing room to concreting cutting steaming curing,last,there will bacome the light brick,the porous rate is 70-80%.
3. AAC block production line , Autoclaved Areated concrete block machine Advantages
light weight
Areated concrete density is usually 400-700kg/m3,(according the market in produce ),same as 1/3 of clay brick and 1/5 common concrete.So use the Light brick can reduce the weight of the build more,and also reduce the beam of roof and pillar press best.then you can see,it can save the material and cost,it also fighting shaking.
keeping temperature
It has many porous,the delivery hearting coefficient is 0.9-0.22W/(mk),the same as 1/4 or 1/5 of clay brick,so it is best materials now in the world. Also many kinds raw material,have lowest wasteMain Material:coal ash sand waste mine material coal stone,stone dust and other silicon materials.
General specification of AAC block production line, autoclave aerated concrete block( mm )
L |
W |
H |
600 |
100 120 125 150 180 200 240 250 300 |
200 240 250 300
|
Size deviation of autoclave aerated concrete block
Item |
Standard |
||||||
High-class product(A) |
Qualified product(B) |
||||||
Allowed size deviation/ mm |
Length |
L |
±3 |
±4 |
|||
Width |
B |
±1 |
±2 |
||||
Height |
H |
±1 |
±2 |
||||
Aera and labour need :
Needs 24-32labour for whole AAC factory running plant , the land needs 5600M2-10,000M2 according to different capacity.
Service:
We can give one year warranty time for free service , in the period , we can send our engineer to customers place for installaion and training . For any help in the machine whole using life , you can feel free to contact with our after sale deparment for 24 hours . We have set up many sale offices and after-sale offices around the world .
Instructions of AAC Production Line from--Hongfa
Products programme
1,Technological Standard
The technological standard of this project is superior products according to the Chinese national standards. The equipments are made according to Chinese standard and criterion.
This project provides the mature tilting technology in China.
2,Capacity
The product is AAC blocks with the capacity of 30,000m3- 300,000m3/year
3. Product specification
The products reach the block requirements of grade 04~07 of GB11968-2006.
Ball MILL can treat the sand and lime raw material
cutting machine for cutting the size of AAC blocks as your size
autoclave for steaming the blocks
If you are interested in ,pls feel free to contact Linda at +86-15264934636 or my skype:linda112637& WhatsApp:0086-13256512899
