QT6-15C high productivity high density block making machine

Specifications

QT6-15C high productivity high density block making machine
Digital control system and sensor technology
Diagnosis

QT6-15C high productivity high density block making machine



♥ Vibration system contains platform vibration and mould vibration.The platform vibration is drived by hydraulic oil and program,bring a vertical and synchronal vibration and achieving low frequency in feeding material,high frequency making.According to diffirent product,we can change the vibration.



♥The feeding system adopts active compulsive feeding technique.On the affect of feeding tooth,it can feed material average,which is propitious to thin products.



♥Application of digital control system and sensor technology combined with effective and makes all act exactness and trustiness.So that it is the same with diffirent condition.The adoption of a variety of advanced technology is easy to be operated.This system is of fault diagnosis system.



Productivity



	Sample	Size	Quantity/Mould	Cycle moulding	Per day
Hollow brick		400*200*200	6pcs	16-20s	10800pcs
Hollow brick		400*150*200	9pcs	15-18s	16200pcs
Color brick		225*122.5*50	18pcs	14-17s	40500pcs



 Main Parameter



1 overall dimension:8200*1700*2950mm

2 rated pressure:21Mpa

3 main vibration form:platform vibration

4 vibration frequency:2800-4500( r/min)

5 pallet size:880*850mm

6 molding cycle:15-25s

7overall power:42.6kw



Quotation :



No	Item	Model	Unit	Qty	Remarks
1	Host machine		set	1	FOBQingDao
2	Pallets feeder		set	1
3	Blocks receiver		set	1
4	Hydraulic unit		set	1
5	Electric cabinet		set	1
6	Belt conveyor		set	1
7	Hopper		set	1
8	Mould		set	1
9	JS500 Compulsive mixer		set	1
10	Conveyor belt		set	1
11	Stacker	for QT6-15c	set	1
12	Hydraulic trolley		set	1	Free
13	Pallets	880*850*25	pcs	1000	Optional



Note:



1. All prices are based on FOB, QINGDAO, China

2. Payment:By T/T 30% downpayment,70% upon machinery completion.

3. Delivery: 10 days upon receipt of downpayment .

4 .SHIPPING MARKS:

5. We test brick making for every machine before delivery

6. Voltage and Hertz Demand: Depended on customer.

7.Package: nude

8.Warranty:The seller assure that provide for 100% new equipment. And the seller assure that the length of warranty about the equipment and motor from date of contract is one year.If the buyer’s technicists didn’t follow the instructions of products, the buyer should take the responsibility. But the seller is out of this kind of this direct and indirect errors .
