Introduction:
Paddle mixer consists of horizontal shell, drive unit, double shaft paddle. Lumps breaker (patent technology) is optional.
The counter rotation paddles moves through the mixture throwing it in air in a weightless status due to high line speed.
The rising and dropping makes materials crossing and results in uniform mixing. It can be bomb door or small opening door for discharging, while bomb door features rapid discharging and no residue.
Flap valve or bomb door is available for the discharge, bomb door for discharge is quick and with no residue.
Application:
Paddle mixer is applied for mixing with powder and powder, granulate and granulate, granulate or powder and a little liquid. It’s widely used for chemical, dry mortar, pesticide, ceramic, foodstuff, feed and battery industry etc.
It is mixing equipment with high precision, can be widely used for mixing goods with large difference in density, feeding ratio, particle size, and has good mixing effect even for feeding ratio large as: 1:1000~10000. High chopper is optional for breaking the practical materials.
A. Homogeneous Mixture
B. Chopper device is optional.
C. Pneumatic bomb door is optional.
Technical parameters:
Model |
Total volume (M³) |
Loading coefficient |
Motor power (KW) |
Dimension (mm) Max. diameter × height |
Weight (kg) |
WZ-0.05 |
0.05 |
0.4-0.6 |
1.5 |
1290×660×837 |
230 |
WZ-0.2 |
0.2 |
0.4-0.6 |
4 |
1124×1110×720 |
260 |
WZ-0.4 |
0.4 |
0.4-0.6 |
4 |
1400×1250×1030 |
450 |
WZ-0.5 |
0.5 |
0.4-0.6 |
7.5 |
1450×1500×950 |
800 |
WZ-1 |
1 |
0.4-0.6 |
11 |
1800×1800×1350 |
1150 |
WZ-1.5 |
1.5 |
0.4-0.6 |
15 |
1850×1950×1180 |
1500 |
WZ-2 |
2 |
0.4-0.6 |
18.5 |
2200×2400×1600 |
2800 |
WZ-2.5 |
2.5 |
0.4-0.6 |
22 |
2300×2300×1620 |
4200 |
WZ-4 |
4 |
0.4-0.6 |
22 |
2680×2400×1850 |
4500 |
WZ-5 |
5 |
0.4-0.6 |
37 |
2950×3050×2040 |
6000 |
WZ-6 |
6 |
0.4-0.6 |
45 |
3050×3250×2100 |
7000 |
WZ-10 |
10 |
0.4-0.6 |
55 |
3550×3150×2400 |
8000 |
WZ-12 |
12 |
0.4-0.6 |
55 |
4695×3180×2500 |
10500 |
WZ-15 |
15 |
0.4-0.6 |
55 |
4180×3960×2600 |
10000 |
WZ-20 |
20 |
0.4-0.6 |
75 |
5700×3700×2500 |
13000 |
Structure:
