Help CenterHigh Quality Screw Conveyor for Sugar Flour Coffee Powder
Related Products
-
China Supplier Customized Structure Flexible Screw ConveyorUS$ 1,000 - 8,000MOQ: 1 Set -
U-type Carbon Steel or Stainless Steel Screw ConveyorUS$ 1,000 - 2,500MOQ: 1 Set
-
Stainless Steel Tubular Screw Conveyor for Conveying Bulk MaterialsUS$ 2,000 - 10,000MOQ: 1 Set
-
ISO China Supplier Flexible Screw Conveyor for GrainUS$ 2,000 - 10,000MOQ: 1 Set
-
China Supplier Spiral Screw Conveyor, Screw Conveyor ManufacturerUS$ 1,000 - 2,500MOQ: 1 Set
Description
2.Low noise, strong adaptability and easy operation
3. Easy for maintenance and long service life
4.ISO,TUV,SEW,FLENDER.
Introduction
Screw conveyor can transport small lumplish material of various powder, grain level or have an angle(the angle less than 200). Its work environment temperature is form -200C to +500C, the temperature of material which was transport should be lower +2000C.
Application
1. Power plant, grain or oil,chemical, metallurgical, paper making and so on.
2. Cement, concrete, coal dust, soda ash, flour, sugar,coffee,grain, paper pulp, etc.
Working principle
When the drive device starts, the helical blade in the case push the material and make the material do axial movement. The material can be discharged at the proper outlet at the bottom of case . Conveyor with simple construction, be able to feed and discharge in many position, it is easy to operate, have good seal capability and environmental friendly.
Performance Features
1. Simple structure, good sealing, good quality ,large capacity, easy operation and low power invest cost.
2. Working temperature is -20~50°C, with material temperature below 200°C.
3. Axle head and conveying spiral adopt spline connection, with features of convenient mounting&diassembling, large load capacity and stability.
4. All sections of screw conveyor are connected with flange. Screw blades are integral connection.
5. Inlet and outlet chutes have many kinds of connections, such as flange, sack, universal joint, etc.
Component show
Site picutre
Technical parameter
Type |
GX150 |
GX200 |
GX250 |
GX300 |
GX400 |
GX500 |
GX600 |
Screw diameter(mm) |
150 |
200 |
250 |
300 |
400 |
500 |
600 |
Pitch (mm) |
120 |
160 |
200 |
240 |
320 |
400 |
480 |
Rotational speed (rpm) |
31-129 |
31-114 |
31-102 |
31-88 |
31-88 |
31-75 |
31-59 |
Capacity (t/h) |
1.3-55 |
3.1-11 |
6-20 |
10-30 |
25-71 |
49-118 |
85-162 |
Allowable speed ratio |
0.013 |
0.03 |
0.06 |
0.1 |
0.25 |
0.48 |
0.85 |
Allowable contilever load(kg) |
210 |
370 |
580 |
800 |
1500 |
2400 |
3500 |
Packaging and shipping
1. Export packing.(Wooden case, carbon cast and pallet).
2. Container (as customer requirements)
3. It is suitable for long distance ocean transportation.
Our service
I. Engineers abailable to service machinery overseas.
2. Provide installation guide, equipment manuals, operation and repair training.
3. Provide random spare parts.
FAQ
Please tell us the following technical parameters before inquiry:
Q: What 's the material will be conveyed?please tell us more material features.
Q:What's the conveying length between the inlet and outlet?
Q:What's the conveying capacity do you want?
Company certificates
Advanced processing equipments
Other information
Welcome to consult our company and products.
