Home > Products > Bucket elevator > Superior quality Grain z shape bucket elevator for export
Superior quality Grain z shape bucket elevator for export
- 120 Set / Sets per Month
- Shanghai Tianjin Qingdao
- T/T L/C D/P D/A Credit Card PayPal
Product Details
Condition: | New | Type: | Bucket Conveyor | Material: | Other, Carbon steel |
Material Feature: | Heat Resistant | Structure: | Conveyor System | Load Capacity: | 5~480 t/h |
Place of Origin: | Hubei, China | Brand Name: | YIJI | Model Number: | TZD200~1000 |
Voltage: | 380v or customized | Power(W): | 1.5~160kw | Dimension(L*W*H): | Decided by the model |
Certification: | ISO2001 | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
1. Z shapebucket elevator Rectangular closed case with double channels.
2. Flanged structure and bolt connection.
3.Max lifting height and capacity.
4. With rich production and aftersale rich experience.
5. ISO,TUV,SEW,FLENDER.
Superior quality Grain z shape bucket elevator for export
Application scope
Z shape bucket elevator is widely used in grain and oil, metallurgy, cement, chemical, light industry and so on. It is used for lifting grain ,piece coal, crushed stone, mineral stone, egg stone, dry and bulk and fluidity power, granular and block material and so on. The material density is not more than 2 t/m3, the site temperature is not more than 2500C.
Operating principle
When the driving device start working , it drives the puley to make the BELT with plastic buckets to do the circular movement from the below of the tail to the top of the head The head section has outlet and the tail section has inlet.
The bucket is filled with material and run to the head section, then the material is thrown out from the outlet under the action of centrifugal force according to the parabolic design.With the running, the empty bucket is back to the below tail section and be filled material from the inlet again,then be lifted up to do parabolic discharge movement . So this cycle finish the vertical transport of materials.
Z shape bucket elevator Features
1.It need small installation space and can lift more materials. it can convey the grain, for example wheat, soybean , corn etc.
2.The transmission capacity is large, it is up to 800 t/h.
3.Long use life.
Z shape bucket elevator parts
Z type bucket elevator in producing
Z shape bucket elevator site picture Technical parameter
Type | TZD200 | TZD250 | TZD300 | TZD400 | TZD500 | TZD650 | TZD800 | TZD1000 |
Belt width(mm) | 200 | 250 | 315 | 400 | 500 | 650 | 800 | 1000 |
Bucket Capacity (L) | 1.21 | 2.35 | 3.1 | 6.1 | 11.5 | 2*3.1 | 2*6.1 | 2*11.5 |
Bucket pitch(mm) | 105-300 | 125-150 | 145 | 195 | 255 | 145 | 195 | 255 |
Belt speed (m/s) | 1.76-2.75 | 1.76-3 | 1.93-3.05 | 1.93-3.05 | 1.97-3.1 | 2.2-3.87 | 2.5-3.94 | 2.5-3.94 |
Capacity (t/h) | 10-50 | 30-100 | 50-150 | 80-150 | 100-200 | 150-300 | 200-400 | 400-600 |
Max lifting height (m) | 60 | 60 | 65 | 65 | 65 | 65 | 65 | 65 |
Packaging and shipping
1. Export packing.(Wooden case, carbon cast and pallet).
2. Container (as customer requirements)
3. It is suitable for long distance ocean transportation.
Bucket elevator is not standard product, please tell us the following technical datas before ordering:
Q: What 's the material will be lifted?please tell us more material features.
Q:What's the lifting height between the inlet with outlet?
Q:What's the lifting capacity do you want?
Advanced processing equipment
Qualification certificate
Contact Us
- Hubei Yidu Yunji Mec. and Elec. Co., Ltd.
- Contact nameLisa .
- Phone86-717-4843222
- AddressEast of Luxun Road
