Specifications
1. Bucket Elevator with Rectangular closed case WITH double channel.
2. Flanged structure and bolt connection between sections.
3.Max lifting height 80 m
4.High efficiency.
5.ISO,TUV,SEW,FLNEDER
Poultry Feed Conveyor Bucket Elevator from China Manufacturer
Features
1. It has compact structure and small overall dimensions of transect and floor space can be saved remarkably
2. Head: rubber covering technology is adopted for head pulley to increase friction coefficient and improve the driving efficiency, height of discharging section of head is increased, thus extending the materials discharging time
And it is fitted with outlet adjusting plate and buffer chamber to effectively reducing the returning of materials
The housing is lined with replaceable UHMW wear proof materials
3. Middle casing: the edge meshing technology is adopted, resulting in high strength and good tightness
The balancing pipe is added to balance the pressure between two housing of machine body
Wide opening access door facilitates the repair and replacing of bucket
Explosion- proof port is available and can effectively reduce pressure and release explosion
4. Foot: new type shaft sealing structure prevents dust from leaking
Split structure of bearing housing guarantees the reliability of use of machine
Two sealing devices in the adjusting plate prevent the dust and materials from leaking out of the adjusting plate
5. The machine is fitted with anti-reverse device so as to avoid the blockage caused by power failure
6. Speed detector and off track alarm sensor are optional
7. It can be used for granular, powdery and blocky materials vertical conveying and widely used for feed mill, oil plant, food, chemicals, construction materials, grain warehouse and port
Bucket Elevator part
site picture
Technical parameter
Type |
TZD200 |
TZD250 |
TZD300 |
TZD400 |
TZD500 |
TZD650 |
TZD800 |
TZD1000 |
Belt width(mm) |
200 |
250 |
315 |
400 |
500 |
650 |
800 |
1000 |
Bucket Capacity (L) |
1.21 |
2.35 |
3.1 |
6.1 |
11.5 |
2*3.1 |
2*6.1 |
2*11.5 |
Bucket pitch(mm) |
105-300 |
125-150 |
145 |
195 |
255 |
145 |
195 |
255 |
Belt speed (m/s) |
1.76-2.75 |
1.76-3 |
1.93-3.05 |
1.93-3.05 |
1.97-3.1 |
2.2-3.87 |
2.5-3.94 |
2.5-3.94 |
Capacity (t/h) |
10-50 |
30-100 |
50-150 |
80-150 |
100-200 |
150-300 |
200-400 |
400-600 |
Max lifting height (m) |
60 |
60 |
65 |
65 |
65 |
65 |
65 |
65 |
Packaging and shipping
1. Export packing.(Wooden case, carbon cast and pallet).
2. Container (as customer requirements)
3. It is suitable for long distance ocean transportation.
Our service
I. Engineers abailable to service machinery overseas.
2. Provide installation guide, equipment manuals, operation and repair training.
3. Provide random spare parts.
FAQ
Please tell us the following technical parameters before ordering:
Q: What 's the material will be lifted?please tell us more material features.
Q:What's the lifting height between the inlet with outlet?
Q:What's the lifting capacity do you want?
