Unique Design High Efficient TH Bucket Elevator for Lifting Bulk Materials

Name: Unique Design High Efficient TH Bucket Elevator for Lifting Bulk Materials
Brand: YIJI
SKU: 139871177

Unique Design High Efficient TH Bucket Elevator for Lifting Bulk Materials thumbnail-1

Unique Design High Efficient TH Bucket Elevator for Lifting Bulk Materials thumbnail-2

Unique Design High Efficient TH Bucket Elevator for Lifting Bulk Materials thumbnail-3

Unique Design High Efficient TH Bucket Elevator for Lifting Bulk Materials thumbnail-4

Unique Design High Efficient TH Bucket Elevator for Lifting Bulk Materials thumbnail-5

Unique Design High Efficient TH Bucket Elevator for Lifting Bulk Materials thumbnail-6

Unique Design High Efficient TH Bucket Elevator for Lifting Bulk Materials photo-1

Unique Design High Efficient TH Bucket Elevator for Lifting Bulk Materials photo-2

Unique Design High Efficient TH Bucket Elevator for Lifting Bulk Materials photo-3

Unique Design High Efficient TH Bucket Elevator for Lifting Bulk Materials photo-4

Unique Design High Efficient TH Bucket Elevator for Lifting Bulk Materials photo-5

Unique Design High Efficient TH Bucket Elevator for Lifting Bulk Materials photo-6

US$ 2,000 - 8,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Condition:

New

Type:

Other, bucket elevator

Material:

Other, Carbon steel

Contact Supplier Request Quote Chat Now

Hubei Yidu Yunji Mec. And Elec. Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai Tianjin Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Type Other, bucket elevator

Material Other, Carbon steel

Material Feature Heat Resistant

Structure Conveyor System

Load Capacity 35~185 t/h

Place of Origin Hubei, China

Brand Name YIJI

Model Number TH315~630

Voltage 380v or customized

Power(W) 1.5~160kw

Dimension(L*W*H) Specific Models

Certification ISO9001:2008

After-sales Service Provided Engineers available to service machinery overseas

Product Description

Unique design high efficient bucket elevator for lifting bulk materials

TH series Bucket Elevator is designed and manufactured according to the national standard, with the round link chain as the dragging chain. There are two type of buckets: ZH type,(middle-deep bucket), generally suit for conveying those wet, easy to agglomerate, hard to thrown out materials, such as wet sand, foundry sand, fertilizer, alkali powder, etc. SH type (deep bucket) generally suit for conveying those dry, loose and easy to throw materials, such as cement, gravel, coal etc.

Specification

1. The Nation Standard maker of TH bucket elevator.
2. WIth a large capacity.
3. Carbon steel structure.
4. ISO,TUV, SEW, FLENDER.

Product Application

Bucket elevator has become a widely used equipment for bulk material transportation, it is widely used in metallurgy, building materials, electric power, chemical, cement, coal, port, wharf, mine, oil, food, feed and other industries.

Main Features

1. Bucket elevator with Simple structure ,easy in installation and maintation.
2.The heat resistant steel as the main parts make it handle high temperature big bulk density materials.
3. Running in a high automatization.
4. Can be loaded and unloaded on multiple points.

Technical Parameters of TH Bucket Elevator
Equipment Type	TH315		TH400		TH500		TH630
Bucket type	Zh	Sh	Zh	Sh	Zh	Sh	Zh	Sh
Capacity(m3/h)	35	59	58	94	73	118	114	185
Capacity (L)	3.75	6	5.9	9.5	9.3	15	14.6	23.6
Bucket distance(mm)	512	512	512	512	688	688	688	688
Diameter* pitch (mm)	Φ18*64				Φ22*86
Chain Broken load(KN)	≥320	≥320	≥320	≥320	≥480	≥480	≥480	≥480
Bucket speed (m/s)	1.4	1.4	1.4	1.4	1.5	1.5	1.5	1.5
Driving wheel speed (rpm)	42.5	42.5	42.5	42.5	35.3	35.3	31.8	31.8

Detailed Images

Machine Parts

Name: Chain

Brand: YIJI

Original: China

1. Take tempering, carburizing and other heat treatment, improve wear resistance.
2. High quality stainless steel or customized material.
3. With high temperature resistance and high tensile strength.

Main Features

Name: Buckets
Brand: YIJI
Original: China

1. Carbon steel or customized material.

2. With high temperature resistance and high tensile strength.

3. Wear resistance.

Certifications

Protection device

Plugging alarm device

Device Type: A059

Switch Type: Limit switch

It is installed on the end cover plate of the head. When the material height exceeds the set value, the alarm signal is sent out to control the height of the material layer.(See red part in the picture.)

Speed Sensor

Device Type: A032
Switch Type: Proximity switch
It is installed in the tail of the tail shaft and tail shaft to rotate together. When the speed exceeds the set range, it transmits a signal to the control system, so as to control the start and the stop of the motor to protect the equipment operation.

Our Service

Pre-Sales Service

* Inquiry and consulting support.

* Sample testing support.

* View our Factory.

After-Sales Service

* Training how to instal the machine, training how to use the machine.

* Engineers available to service machinery overseas.

Packing & Delivery

Packaging
Size	600(L) * 300 (W) * 270 (D)
Weight	10T
Packaging Details	The closed package is iron box(Size: LWH). Use the iron box to pack the parts that need to be protected, such as electric motors, speed reducer, electrical control equipment and so on. We also can packe it according to customers special request.

Packaging
Size	600(L) * 300 (W) * 270 (D)
Weight	10T
Packaging Details	The Non standard package is iron frame(Size: LWH). We use the iron frame to package some overall and larger components, such as the head, tail, middle section. We can pack it according to customers special request.
