China professional heavy-duty heat resistant Vertival Chain Bucket conveyor for slag of power plant
Vertival Chain Bucket conveyor is designed basis the nation relevant standard, and adopts gravity to unload material. It uses plate type bushed roller chain as the drag part, and is suitable for to transport the materials which pile up the specific weight is not more than a 2t/m3,or the piece degree is 55mm, 50mm or 110mm, and the material temperature is not more than 250 degrees, such as piece coal, crushed stones, mineral stone, egg stone and so on. The capacity is 16~480m3/h, the lifting height is 5~40m.
Specification
1. The Nation Standard maker of vertical Chain bucket conveyor .
2. WIth a large capacity.
3. Carbon steel structure.
4. ISO,TUV, SEW, FLENDER.
Product Application
Vertival Chain Bucket conveyor has become a widely used equipment for bulk material transportation, it is widely used in power plant,metallurgy, building materials, electric power, slag, chemical, cement, coal, port, wharf, mine, oil, food, feed and other industries.
Main Features
1.Vertival Chain Bucket conveyor with Simple structure ,easy in installation and maintation.
2.The heat resistant steel as the main parts make it handle high temperature big bulk density materials.
3. Running in a high automatization.
4. Vertival Chain Bucket conveyor Can be loaded and unloaded on multiple points.
Machine Parts
Name: Chain
Brand: YIJI
Original: China
1. Take tempering, carburizing and other heat treatment, improve wear resistance.
2. High quality stainless steel material.
3. With high temperature resistance and high tensile strength.
Main Features
Name: Buckets
Brand: YIJI
Original: China
1. Carbon steel material.
2. With high temperature resistance and high tensile strength.
Plugging alarm device
Device Type: A059
Switch Type: Limit switch
It is installed on the end cover plate of the head. When the material height exceeds the set value, the alarm signal is sent out to control the height of the material layer.(See red part in the picture.)
Speed Sensor
Device Type: A032
Switch Type: Proximity switch
It is installed in the tail of the tail shaft and tail shaft to rotate together. When the speed exceeds the set range, it transmits a signal to the control system, so as to control the start and the stop of the motor to protect the equipment operation.
Pre-Sales Service
* Inquiry and consulting support.
* Sample testing support.
* View our Factory.
After-Sales Service
* Training how to instal the machine, training how to use the machine.
* Engineers available to service machinery overseas.
