spiral classifier
Spiral washing machine is mainly applied to washing minerals of large slit content, such as iron, manganese, limestone, tin ore, etc. it is suitable for washing building materials in construction and power station applications. The gear transmission parts of our spiral washing machine are separated from stones, water and sands, which greatly reduces the error rate of our spiral washing machine.
Features:
Spiral washing machine has features like long spiral structure,good sealing system,simple structure,strong processing capability,convenient maintenance, good washing efficiency, etc.It is widely used in mining industry.
Working Principle:
Spiral washing machine makes use of buoyancy of water to separate sand from dust and impurity. It achieves purifying, lifting and conveying of the minerals through the stirring of spiral slice. During lifting, the minerals are also stirred so that the coarse sands and fine sands are evenly mixed.
Technical parameter of Spiral classifier
Model |
Spiral diameter |
Spiral rotation speed |
Trough length |
Motor power(kw<=) |
Dimensions (mm<=) |
Weight |
|||
For driving |
For lifting |
Length |
Width |
Height |
<= |
||||
FG-5 |
500 |
8-12.5 |
4500 |
1.1 |
--- |
5430 |
680 |
1480 |
1.6 |
FG-7 |
750 |
6-10 |
5500 |
3 |
--- |
6270 |
980 |
1820 |
2.7 |
FG-10 |
1000 |
5-8 |
6500 |
5.5 |
--- |
7590 |
1240 |
2380 |
4 |
FC-10 |
8400 |
7.5 |
9600 |
1240 |
2680 |
6 |
|||
FG-12 |
1200 |
4-6 |
6500 |
7.5 |
2.2 |
8180 |
1570 |
3110 |
8.5 |
FC-12 |
8400 |
7.5 |
2.2 |
10370 |
1540 |
3920 |
11 |
||
2FG-12 |
6500 |
15 |
4.4 |
8230 |
2790 |
3110 |
15.8 |
||
2FC-12 |
8400 |
15 |
4.4 |
10370 |
2790 |
3920 |
17.6 |
||
FG-20 |
2000 |
3.6-5.5 |
8400 |
11-15 |
3 |
10790 |
2530 |
4490 |
20.5 |
FC-20 |
12900 |
11-15 |
3 |
15610 |
2530 |
5340 |
28.5 |
||
2FG-20 |
8400 |
22-30 |
6 |
11000 |
4600 |
4490 |
35.5 |
||
2FC-20 |
12900 |
22-30 |
6 |
15760 |
4600 |
5640 |
48.7 |
||
FG-24 |
2400 |
3.67 |
9130 |
15 |
3 |
11650 |
2910 |
4970 |
25.7 |
FC-24 |
14130 |
18.5 |
4 |
16580 |
2930 |
7190 |
41 |
||
2FG-24 |
9130 |
30 |
6 |
12710 |
5430 |
5690 |
45.8 |
||
2FC-24 |
14130 |
37 |
8 |
17710 |
5430 |
8000 |
67.9 |
||
2FG-30 |
3000 |
3.2 |
12500 |
40 |
8 |
16020 |
6640 |
6350 |
73 |
2FC-30 |
14300 |
17091 |
8680 |
84.8 |
|||||
...
