Good Quality Ceramic and Raw Material Raymond Mill

Good Quality Ceramic and Raw Material Raymond Mill thumbnail-1
Good Quality Ceramic and Raw Material Raymond Mill photo-1
US$ 10 - 10,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Other, cement mill/raw material mill with yf brand
Motor Type:
AC Motor
Contact Supplier Request Quote Chat Now
Zhengzhou Yufeng Heavy Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
tianjin/shanghai/qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Other, cement mill/raw material mill with yf brand
Motor Type AC Motor
Power(W) 380kw
Capacity(t/h) 15-30
Place of Origin Henan, China
Brand Name Yufeng brand
Model Number cement mill/raw material mill with yf brand
Dimension(L*W*H) as the different models
Weight 50 t
Certification ISO, CE
Warranty 2 years
After-sales Service Provided Engineers available to service machinery overseas

  Good Quality Ceramic and Raw Material Raymond Mill,  an efficient tool for fine finishing, is made of fine materials skillfully. It can grind many kinds of ore and other materials, thus it is widely used in powder-making production line including cement, silicate, new-type building material, refractory material, chemical materials, ore dressing, ferrous metal and non-ferrous metal, glass ceramics industries, etc



Operating Principle

raymond mill consists of a horizontal cylindrical shell, provided with renewable wearing liners and grinding medium-steel balls. Inside the low-speed rotating shell, steel balls cling to the liner under the influence of inertia, friction and centrifugal force. Then they will be taken to a certain height and thrown down due to the gravity and centrifugal force. In this process, the materials continuously dropped from one end of the cylinder will be smashed by the balls. In adittion, both the balls and materials will be rolling and sliding irregularlly together. Therefore, the materials will become finer and finer.



Features and advantages

1. high efficiency and energy- saving

2. widely application

3. Easy and safe operation
4. Stable performance

5. Even product size

Main Technical Parameters of Cement Ball Milling

Specification

Output

(t/h)

Rev (r/min)

Grinding Body

(t)

Electricmotor

Reducer

Model

Power

(kw)

Model

Ratio of Speed

2.2x75

material22

21.4

31

JR158-8

380

ZD70-9

5

2.2x11

material22-26

21.4

49

JR1512-8

630

ZDH80-4

4.5

2.2x12

material26-30

21

58

YR630-8

630

JS-90

35.2

2.4x7.5

material21-23

20.4

28

JR158-8

380

NZD450-5

5

2.4x8

material23-25

21.3

30.5

YR630-8

500

ZDH80

5

2.4x(8+1.5)

material24-26

20.9

39

YR630-8

500

ZDH80A-5

5

2.4x12

material35-38

20

55

YR800-8/1180

800

ZD100A-41

6.43

2.4x13

material35-38

19.4

70

YR800

800

JDX800/MBY800

6.33

2.6x13

material50-55

19.5

82

YR1000-8/1180

1000

JDX800/MBY800

4.5

2.8x5+3

material36-47

18.6

32

YR500-8

500

ZDH80

4.5

2.8x10

material40-48

19.7

52

YR800-8/1180

800

D110A(1)

  37.5

3x(9.25+1.75)

material45

17.8

70

YR1000-8/1180

1000

JDX800/MBY800

6.3

3x11

material45-48

18.7

50

YR800-8/1180

800

ZD100A

6.43

3x12

material55-58

18

95

YR1250-8/1430

1250

JS110-A

41.1

3.2x7+D

material50

17.8

58

YR1000-8/1180

1000

JDX800/MBY800

4.5

3.2x9

material65

17.6

90

YR1250-8/1180

1250

JS110-A

184.5

3.2x10

material55

17.6

65

YR1000-8/1180

1000

JS100

41.5

3.4x(7.5+1.8)

material60

17.2

70

YR1000-8/1430

1000

JDX900/MBY900

6.3

3.5x10m

material75

16.6

80

YR1250-8/1430

1250

JDX900/MBY900

6.3

3.8x7.5

material85

16.7

85

YR1400-8/1430

1400

JDX900/MBY900

7.1

3.8x(7.5+1.5)

material75

16.7

85

YRKK900-8

1400

JDX900/MBY900

46.5

4.6x(8.5+3.5)

material150

15

150

YRKK900-8

2800

JS140-A-F1

49.5

4x10+3.5

material110-130

16

150

YRKK900-8

2500

JS130-C

46.5
