Full automatic vertical ring die wood pellet machine
Brief of vertical ring die wood pellet machine
wood pellet machine can produce 4-12mm pellets, last pellet length can be adjusted optionally. The wood pellet machine is mainly applicable to crude fiber granulation ,such as: sawdust, rice husk ,cotton stalk, cotton seed hull, weeds and all kinds of crop straw, home wastage, waste plastics and the factory waste, the material of low adhesion rate, difficult to forming.
This type of pellet mill is widely used in the biomass-energy fuels plant, power plant, wood processing plant etc. It is the ideal pressing shaping equipments with low investment and high profit.
Advantages of vertical ring die wood pellet machine
1. vertical feeding
2. roller rotate,Centrifugal force role ,material distribute uniformly
3. two layer roler,saving cost ,good effect.
4. ring die,vertical structure, help pellet room temperature reducing
5. seperate discharging structure, improve the pellet forming rate
6. with good lubricate device, protect the machine bearing
7. feeding device with frequency conversion
After sales of vertical ring die wood pellet machine
1.Guarantee period is 13months, since the date of purchasing (with invoice), if there are failure issues due to manufacturing quality during this 13 months, factory will be responsible for the maintenance for free. (Die, rollers, bearing, spare parts are not included).
2.If failure or damage caused by the user’s improper operation, our factory will provide paid services.
3.Users need service, please contact our factory.
4. New drawing and technical parameters will change without notice to the user, please understand.
Vertical Ring Die Wood Pellet Machine Technical Parameters
|
|
Pellet size |
Inner dia.(mm) |
Production(t/h) |
Dimension(mm) |
Weight(t) |
YFK450 |
55 |
Φ4-Φ12 |
450 |
0.3-1 |
2200x900x1600 |
3 |
YFK550 |
75 |
Φ4-Φ12 |
550 |
0.7-1 |
2300x1000x1780 |
5 |
YFK560 |
90 |
Φ4-Φ12 |
560 |
1-1.5 |
2600x1300x2300 |
6.3 |
YFK580 |
160 |
Φ4-Φ12 |
580 |
1.5-2 |
2900x1300x2400 |
7.5 |
YFK680 |
160 |
Φ4-Φ12 |
680 |
2-2.5 |
3200x1400x2400 |
8.5 |
YFK850 |
220 |
Φ4-Φ12 |
850 |
2-3 |
3750x1650x3250 |
12.6 |
YFK880 |
315 |
Φ4-Φ12 |
880 |
3-4 |
4300x1900x3600 |
14.5 |
Output pellets from vertical ring die wood pellet machine
Parameters of the output pellets | |
calorific value |
>4500~4800 kcal/kg |
density |
>1.1~1.3t/m3 |
moisture |
<=10% |
combustion ratio |
>=98% |
heat efficiency |
>=81% |
ringelman emittance |
<1 |
discharged dust consistence |
<=80mg/m3 |
Ash content |
<=2% |
Before supplying our proposal List, we need to know:
A.What capacity would your prefer?-----The capacity for vertical ring die pellet mill model
YFK560 is 1-1.5T/H, 580 is 1.5-2T/H
B.What is your raw material?-----According to different raw material(such as hard wood,soft
wood,straw,rice husk), capacity is different.
C.What is your raw material size?-----Best size for pressing high quality pellets is less than 4mm.
D.What is the moisture of your raw material?-----Better to be 10-15%.
Packing and shippment:
Any questions, please feel free to contact Marcie timely:
...
