XPS Extruder Machine Foam Board Production Line CO2 Foaming
XPS foamed board extrusion production line is one of our hi-tech products first successfully developed and sold in China. Depending on continuous improvement and updation, our technical level keeps leading position in China. Poly Styrene foamed board is one kind of good insulating materials with continuous even surface and beehive structure. It has superior advantages of heat preservation, heat insulation, waterproofness and high compression resistance. XPS board has been widely used in the fields of heat preservation and insulation for roof and outer wall, low temperature storage facilities, surface and undersurface of roads. As an ideal heat insulating and dampproof material, it has wide market prospect.
Model |
JG-XPS135/150 |
JG-XPS170/200 |
JG-XPS139/170 (CO2) |
JG-XPS75P/200(CO2) |
|||||
Extruder |
Φ135/32 |
Φ150/34 |
Φ170/28 |
Φ200/32 |
Φ139/32 |
Φ170/36 |
Φ75/36 |
Φ200/36 |
|
Heating power (approx) |
KW |
50 |
52 |
78 |
100 |
70 |
100 |
60 |
80 |
Driving motor power |
KW |
75 |
55 |
90 |
90 |
90 |
90 |
110 |
110 |
Thickness of board |
mm |
20-100 |
40-120 |
20-50 |
25-60 |
||||
Width of board |
mm |
600, 900, 1200 |
600, 900, 1200 |
600 |
600 |
||||
Length of board |
mm |
1200, 1250, 2450, 2500 |
|||||||
Output (approx) |
kg/h |
320 |
380-500 |
250-400 |
320-550 |
||||
Installed capacity (approx) |
KW |
260 |
400 |
300 |
400 |
||||
Dimensions (L×W×H)(approx) |
m |
40×10×4 |
50×12×4 |
45×10×4 |
50×12×4 |
||||
Total weight (approx) |
T |
26 |
33 |
30 |
33 |
||||
For waterproofing, heat preservation and heat insulation in wall and roof of residential buliding, office building, industrial workshop etc. construction industry;
For anti-freezing and heat preservation of the roadbed project such as the highway, railway, airport, etc.
For anti-freezing bulge material of concrete water delivery channel in water conservancy project; (such as divert water project from the south to north);
For heat insulation and heat preservation of the ventilation pipe of central air condition;
For using under the floor of floor heaters project,moistureproof, heat insulation and sound insulation;
For heat insulation board, cold preservation, waterproof of the refrigeration storehouse;
For heat insulation and heat preservation of steel construction workshop, iron wall house and colored ripple tile;
- Q: Can you install the machine in abroad?
- A: Yes, we have our own engineers who can install the machine for the customers in abroad.
- Q: What kinds of certificates can you offer?
- A: We can offer CE certificate and ISO9001:2008 quality attestation system.
- Q: What's about the after-sales service?
- A: We can supply with spare parts and repair tools for free.
- Q: What's about the warranty of your machine?
- A: Normally 12 months.
- For any other questions, you are always welcome to contact us via email or phone. Thank you.
- We have our own factory can provide stability quality, and also we can offer the most reasonable prices.
- We have our own professional sales teams who have rich experiences on the international trade and good technical knowledges.
- We have our own engineers who can install the mahines in abroad for the customers.
