20-50 ton per hour capacity Cement Ball Mill

Specifications

20-50 t/h capacity Cement Clinker Ball Mill for Cement Plant
1.High Efficiency 2.Energy Saving 3. CE and ISO

20-50 ton per hour  capacity Cement Ball Mill



Ball mill is an efficient tool for grinding many materials into fine powder.

1.The Ball Mill is used to grind many kinds of mine and other materials, or to select the mine.

2. It is widely used for the cement, the licate produce, new type building material, chemical fertilizer, blak and non-ferrous metal glass, ceramic and etc.

3.There are two ways of grinding: the dry way and the wet way. It can be divided into tabular type and flowing type according to different expelling mine.



2.  Working Principle of  Cement Ball Mill

 There is grinding medium (steel balls) in the ball mill and the cylinder body is made of steel plate.The cylinder body has the lining plate, which can protect the shell from wearing out. When the feedstock is put into the cylinder body, under the centrifugal force and the friction by the steel balls, the materials can be smashed, the powder can be discharged through the stripper plate, and the whole processing is finished.





3.Structural characteristics of   Cement  Ball Mill





4. Features of Cement Ball Mill  :



1.Large application range, simple structure and convenient maintenance;
2.Large capacity and continuous work are very obvious;
3.Barrel lining and grinding media can apply various abrasive materials;
4.Installation and adjustment are very convenient and easy to be operated.





5. Specification of Ball Mill



Type	Rotary speed(r/min)	Grinding media loading(t)	Feed size(mm)	Discharge size(mm)	Capacity (t/h)	Power(KW)	Weight(T)
Φ900×1800	38	1.5	≤20	0.075-0.89	0.65-2	18.5	3.6
Φ900×3000	38	2.51	≤20	0.075-0.89	1.1-3.5	22	4.6
Φ1200×2400	32	3.8	≤25	0.075-0.6	1.5-4.8	30-45	12.5
Φ1200×3000	32	5	≤25	0.074-0.4	1.6-5	30-45	12.8
Φ1200×4500	32	7	≤25	0.074-0.4	1.6-5.5	55	13.8
Φ1500×3000	27	8	≤25	0.074-0.4	2-5.8	75-90	17
Φ1500×4500	27	14	≤25	0.074-0.4	3-6.5	90-110	21
Φ1500×5700	27	15	≤25	0.074-0.4	3.5-8	110-132	24.7
Φ1830×3000	24	11	≤25	0.074-0.4	4-10	132-180	28
Φ1830×6400	24	23	≤25	0.074-0.4	6.5-15	210	34
Φ1830×7000	24	25	≤25	0.074-0.4	7.5-17	210-245	36
Φ2200×5500	21	30	≤25	0.074-0.4	10-22	370	48
Φ2200×6500	21	31	≤25	0.074-0.4	14-26	380	50
Φ2200×7500	21	33	≤25	0.074-0.4	15-29	475	56
Φ2400×7000	21	39	≤25	0.074-0.4	16-33	475	69
Φ2400×11000	21	51.5	≤25	0.04-0.08	16-35	630	99
Φ2700×3600	21	39	≤25	0.074-0.4	16-29	475	74
Φ2700×4500	21	43.5	≤25	0.04-0.08	20-35	500	80
Φ3200×4500	18	65	≤25	0.074-0.4	25-40	800	137
