Specifications
1.Different models for different material2.Manufacturer with 65 years experiences
7-10 TPH Limestone Grinding ball mill
1. Limestone Grinding mill Application :
Ball mill is an efficient tool for grinding many materials into fine powder.
1>.The Ball Mill is used to grind many kinds of mine and other materials, or to select the mine.
2>. It is widely used for the cement, the licate produce, new type building material, chemical fertilizer, blak and non-ferrous metal glass, ceramic and etc.
3>.There are two ways of grinding: the dry way and the wet way. It can be divided into tabular type and flowing type according to different expelling mine.
2. Limestone Grinding mill Structure:
3. Limestone Grinding mill Working principle:
Ball Mill is a horizontal rotating device transmitted by the outer gear. The materials are transferred to the grinding chamber through the quill shaft uniformly. There are ladder liner and ripple liner and different specifications of steel balls in the chamber. The centrifugal force caused by rotation of barrel brings the steel balls to a certain height and impact and grind the materials. The ground materials are discharged through the discharging board thus the grinding process is finished.
4. Limestone Grinding mill Specification :
|
Specifications (m) |
Capacity (t/h) Close Circuit / Open Circuit |
Effective Volume (m3) |
Feeding Size (mm) |
Rotating Speed (r/min) |
Load of Grinding Media (t) |
Driving mode |
Main Motor |
Main Reducer |
Weight (t) |
||
Type |
Power |
Type |
Speed Ratio |
||||||||
ø1.83 x7.5 |
9.5-10.0 |
17.68 |
≤25 |
23.9 |
22.5 |
Edge |
JR138-8 |
245 |
ZD 60-8 |
4.5 |
40 |
Ø2.2X (6.5+1) (Dry) |
21-25 |
21.3 |
≤25 |
21.4 |
31 |
Edge |
JR15-88 |
380 |
ZD 70-9 |
5 |
50 |
Ø2.2 X13 |
34-38 |
42.4 |
≤25 |
21.4 |
58 |
Edge |
YR630-8 |
630 |
ZD 80 |
5 |
95 |
Ø2.4 X7 |
26-28 |
28.17 |
≤25 |
20.4 |
39 |
Edge |
JR1512-8 |
570 |
ZD 80 |
5 |
72 |
Ø2.4 X8 |
28-30 |
32.2 |
≤20 |
20.4 |
42 |
Edge |
JR1512-8 |
570 |
ZD 80 |
5 |
77 |
Ø2.4 X9 |
36-38 |
36.2 |
≤20 |
20.4 |
45 |
Edge |
JR1512-8 |
570 |
ZD 80 |
5 |
81 |
Ø2.4 X10 |
(open)34-38
(close)40-44 |
40.3 |
≤20 |
20.91 |
50 |
Edge |
YR630-8 |
630 |
MBY630 |
5 |
111 |
Ø2.4 X11 |
(open)34-38
(close)44-47 |
43.4 |
≤20 |
20.91 |
58 |
Edge |
JR1512-8 |
630 |
MBY630 |
5 |
125 |
Ø2.4 X12 |
(open)40-42
(close)45-48 |
46.5 |
≤25 |
21.5 |
64 |
Edge |
YR800-8 |
800 |
MBY710 |
6.3 |
126 |
Ø2.4 X13 |
(open)42-44
(close)48-51 |
49.6 |
≤25 |
21.5 |
70 |
Edge |
YR800-8 |
800 |
MBY710 |
6.3 |
130.6 |
Ø2.6X8.5 |
50-55 |
38.6 |
≤20 |
19.6 |
56 |
Edge |
YR630-8 |
630 |
MBY 630 |
5.6 |
110 |
Ø2.6X10 |
52-55 |
45.47 |
≤20 |
19.6 |
72 |
Edge |
YR1000-8 |
1000 |
MBY 710 |
5.6 |
140 |
|
Ø2.6X13 (Wet) |
50-55 |
60.5 |
≤25 |
19.11 |
80 |
Edge |
YR1000-8 |
1000 |
MBY 710 |
4.5 |
158 |
Ø3x9 |
55-60 |
58.5 |
≤25 |
18.98 |
85 |
Edge |
YR1000-8 |
1000 |
MBY 710 |
5.6 |
147 |
|
Ø3x (8.5+5) (Dry) |
58-62 |
61.5 |
≤25 |
18.98 |
82 |
Edge |
YR1000-8 |
1000 |
MBY710 |
5.6 |
160 |
Ø3.2x9 |
70-75 |
62 |
≤25 |
18.3 |
90 |
Edge |
YR1250-8 |
1250 |
MBY 900 |
6.3 |
175 |
Ø3.5X8 |
75-80 |
68 |
≤25 |
17.1 |
91 |
Edge |
YR1250-8 |
1250 |
MBY 900 |
5.6 |
182 |
|
Ø3.5X10 (Dry) |
80-85 |
85 |
≤25 |
17.1 |
80 |
Center |
YR1400-8 |
1400 |
MBYX 900 |
6.3 |
194 |
|
Ø3.6x (7.5+1.5) (Dry) |
95-100 |
83.7 |
≤25 |
17.05 |
85 |
Edge |
YR1400-8 |
1400 |
MBY900 |
6.3 |
220 |
|
Ø3.8X7.5 (Air-swept) |
85-90 |
82 |
≤20 |
16.7 |
95 |
Edge |
YR1400-8 |
1400 |
MBY800 |
5.6 |
182 |
Ø3.8X7.5 (Dry) |
85-90 |
82 |
≤20 |
16.7 |
103 |
Edge |
YR1400-8 |
1400 |
MBY 800 |
5.6 |
182 |
Ø3.8X12 (Dry) |
135-138 |
108.5 |
≤25 |
16.6 |
112 |
Center |
YR800-8 |
2000 |
MFY 200A JS130-A |
|
295 |
|
Ø4.2x (8.5+2.5) (Dry) |
130-140 |
116 |
≤25 |
15.6 |
130 |
Center double slide shoe |
YRKK 900-8 |
2500 |
MFY 250A JS130- C2 |
|
355 |
|
Ø4.2x (10+3.5) (Dry) |
150-160 |
130 |
≤25 |
15.1 |
160 |
Center double slide shoe |
YRKK 900-8 |
3150 |
MFY 320A JS140-C |
|
400 |
|
Ø4.6x (9.5+3.5) (Dry) |
185-190 |
145 |
≤25 |
15.1 |
180 max |
Center double slide shoe |
YRKK 1000-8 |
3550 |
MFY 355A JS150-B |
|
415 |
|
Ø4.6x (10+3.5) (Dry) |
190-200 |
160 |
≤25 |
15.1 |
190 max |
Center double slide shoe |
YRKK 1000-8 |
3550 |
MFY 355A JS150-B |
|
423 |
|
Ø4.6x (11+3.5) (Dry) |
220-240 |
191 |
≤25 |
15.2 |
258 max |
Center double slide shoe |
YRKK 1000-8 |
4000 |
MFY 400A JS160-B |
|
480 |
