273 Screw Conveyor
It is a compact structure, cross-sectional area is small, light weight, good sealing performance, transmission efficiency, technology and flexible layout, loading, folding, mobile convenience, safe operation.
Applies to transport all kinds of powder, tablets, small block of bulk materials such as clay powder, coal, cement, sand, grains, small lump, pebble, and cast-iron chips and so on. Not suitable for conveying sticky, easy caking, perishable materials.
Configured in the form of screw conveyor according to the level, tilt and mix in the form, and can work with other delivery devices used in conjunction to complete the set of transportation, distribution, mixing, mix, dehydrated, fixed ingredients, unloading, chop Dengxiang heap operations.
The product is particularly suitable for the concrete mixing station from the cement silo to the mixer or from the cement silo to the batching of bulk cement transport between machines.
MODEL/ Technique Parameter |
139 |
168 |
219 |
273 |
323 |
407 |
|||
|
Conveying capacity t/h
|
speed ratio |
1/5 |
13 |
25 |
60 |
|
|
|
|
1/7 |
9 |
17 |
40 |
90 |
150 |
|
|||
1/10 |
6.5 |
12.5 |
30 |
65 |
110 |
170 |
|||
|
diameter(mm)
|
φ120 |
φ140 |
φ190 |
φ240 |
φ300 |
φ350 |
|||
|
speed r/min |
Gear ratio |
1/5 |
280 |
280 |
280 |
280 |
280 |
280 |
|
1/7 |
200 |
200 |
200 |
200 |
200 |
200 |
|||
1/10 |
140 |
140 |
140 |
140 |
140 |
140 |
|||
Out-tube Dia.(mm) |
φ139 |
φ168 |
φ219 |
φ273 |
φ325 |
φ407 |
|||
allows working angle α(0) |
0-45 |
0-45 |
0-45 |
0-45 |
0-45 |
0-45 |
|||
max. transfer length L(m) |
10 |
12 |
13 |
18 |
18 |
18 |
|||
|
motor power (KW) |
L<4 |
L<4 |
L<4 |
L<3 |
L<3 |
L<3 |
|||
1.5 |
3 |
4 |
5.5 |
7.5 |
11 |
||||
L<9 |
L<9 |
L<9 |
L<9 |
L<7 |
L<9 |
||||
2.2 |
4 |
7.5 |
11 |
15 |
18.5 |
||||
L>9 |
L>9 |
L>9 |
L>9 |
L>7 |
L>9 |
||||
3 |
5.5 |
11 |
15 |
18.5 |
22 |
||||
Screw conveyor:
Certificates:
Our factory :
our customer:
Welcome come to our factory.
