Lianchuang Machinery (HLS90) Concrete Batch Plant Layout
US$ 97,900 - 163,200
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Power Type:
Electric
Place of Origin:
Shandong, China
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
HZS180 Concrete Mixing EquipmentUS$ 267,000 - 534,000MOQ: 1 Set -
Russia Construction HZS50 Concrete Batching PlantUS$ 30,000 - 80,000MOQ: 1 Set
-
High Quality !!!!!Concrete Batching Plant HZS40NegotiableMOQ: 1 Set
-
High Quality !!!!!Concrete Batching Plant HZS50NegotiableMOQ: 1 Set
-
High Quality !!!!!Concrete Batching Plant HZS75NegotiableMOQ: 1 Set
Condition
New
Power Type
Electric
Place of Origin
Shandong, China
Brand Name
shandong lianchuang
Model Number
hls90
Power(W)
112kw
Weight
40000-4400kg
Certification
ISO
Warranty
1 year
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
Ready-Mixed Concrete Batching Plant1. Accurate and reliable weighing
2. Well-dosed and efficient mixing
3. Easy to instal
1. the concrete mixing plant has intellectually automatic function;
2. it is intermittent and compulsory concrete batching plant;
3. it has the function of maginificient outside.high productivity
4.it can be used in many manners of combining and material conveyance;
5.it can produce dry-rigid,half dry-rigid, plastic and each distribution ratio concrete.
6.it is the ideal equipment for construction of large and medium-sized construction project such as waterpower engineering, highway,port and manufacturers of large fabricated parts and commodity concrete.
| Main Technical Parameters | ||||||
| Model | HZS60 | HZS90 | HZS120 | HZS180 | HZS200 | |
| Production(m³/h) | 60 | 90 | 120 | 180 | 200 | |
| Mixer | Type | JS1000 | JS1500 | JS2000 | JS3000 | JS4000 |
| Power(Kw) | 2*22 | 2*30 | 2*37 | 2*55 | 2*75 | |
| Output(m³) | 1 | 1.5 | 2 | 3 | 4 | |
| Grain Size(mm) | ≤60 | ≤80 | ≤120 | ≤150 | ≤150 | |
| Batcher | Hopper Capacity(m³) | 13 | 15 | 20 | 25 | 30 |
| Hopper Quantily(pc) | 4 | 4 | 4 | 4 | 4 | |
| Belt Conveyor Capacity(t/h) | 200 | 300 | 400 | 500 | 600 | |
| Weighing Scope And Accuracy | Aggregate(Kg) | 3000±1% | 4000±2% | 5000±2% | 6000±2% | 9000±2% |
| Cement(Kg) | 600±1% | 900±1% | 1200±1% | 1800±1% | 2400±1% | |
| Aduiterant(Kg) | 300±1% | 400±1% | 600±1% | 800±1% | 1000±1% | |
| Water(Kg) | 350±1% | 600±1% | 600±1% | 800±1% | 1000±1% | |
| Admixture(Kg) | 30±1% | 30±1% | 50±1% | 50±1% | 50±1% | |
| Total Power(kw) | ≈78 | ≈102 | ≈145 | ≈196 | ≈245 | |
| Discharge Height(m) | 3.8 | 3.8 | 3.8 | 3.8 | 3.8 | |
