2016 Hot Sale!!! Beatuiful Concrete Mixing Station HZS75

Name: 2016 Hot Sale!!! Beatuiful Concrete Mixing Station HZS75
Brand: Lianchuang
SKU: 139854957
Availability: InStock

US$ 465,000 - 480,000 MOQ: 1 Set

Key Specifications

Condition:

New

Power Type:

Electric

Place of Origin:

Shandong, China

Shandong Lianchuang Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Power Type Electric

Place of Origin Shandong, China

Brand Name Lianchuang

Model Number HZS75

Power(W) 85KW

Weight 35000KGS

Certification ISO9001:2000

Warranty one year

After-sales Service Provided Overseas service center available

The main characteristics of the concrete batching plants series as follows:

1. Adopting twin forced horizontal shafts stirrer

2. The aggregate is measured alone or accumulated by the electronic scale

3. Water and the additive are measured accurately under the centralized control of

the computer

4. The whole machine adopts PC to control, which is easy to operate and debug

5. Model for feeding aggregate: belt transfer

6. The main electric elements are the devices of Schneider in France; the programmable controller is the product of well-known brand

Technical parameters of HZS75 concrete mixing station
Theory productivity	75m³/h
Mixer model	JS1500
Normal volume mixer	1500L
The maximum particle size of mixing aggregate	80mm
Power of mixing motor	2×30kw
Upgrade machines power of aggregate hopper	22kw
Aggregate batching system	PL2400
Volume of aggregate hopper	3×15m³
Batching capacity of aggregate	2400L
Kinds of aggregate	3
Volume and number of powder silo	50t/100t/150t/200t choice according to request of user
Powder screw conveyor	60t/h choice according to request of user
Metering range and accuracy of aggregate G	4000±2kg
Metering range and accuracy of water W	700±1kg
Weighing range and accuracy of cement C	700±1kg
Weighing range and accuracy of fly ash F	400±1kgchoice according to request of user
Weighing range and accuracy of admixture A	50±1kg
Cycle	75S
Discharge height	3800mm
Power of the whole machine	About 110kw (not contain screw conveyor)
Weight of the whole machine	About 39T(not contain screw conveyor and power soil)
External dimension (LWH)	According to the model of disposition and layout
