Specifications
Wet-mix shotcrete machine:1.simple operation ,low dust , low rebound ,
2.high-strength of concrete layer;
Wet-mix shotcrete machine
wet-mix shotcrete machine is an advanced concrete spraying technique, developed from dry-mix shotcrete .
Wet-mix shotcrete machine advantages :simple operation ,low dust , low rebound ,high-strength of concrete layer; reliable performance an so on . Widely be used for Construction Engineering, Mining, Tunnel, Culvert, Hydroelectric Project, Underground Engineering
item |
HSP-5 |
HSP-7 |
HSP-9 |
Output |
4-5 m³/H |
5-7m³/H |
6-9m³/H |
Max. Convey dist |
Horizontal:30m Vertical: 20m |
Horizontal:30m Vertical: 20m
|
Horizontal:30m Vertical: 20m
|
|
Concrete proportion
|
1:4-5C/A |
1:4-5C/A |
1:4-5C/A |
|
Water cement ratio
|
≤0.4 |
≤0.4 |
≤0.4 |
Hose inner size |
Φ51m |
Φ51m/64mm |
Φ51m/64mm |
Max. Aggregate size |
15mm |
15mm |
15mm |
Operating air pressure |
0.3-0.6MPa |
0.4-0.6MPa |
0.4-0.6MPa |
Air consumption |
10-15m³/min |
10-15m³/min |
10-15m³/min |
Rotor diameter |
438mm |
480mm(160) |
480mm(175) |
Spring rate level |
≤10% |
≤10% |
≤10% |
The accelerating liquid adding amount |
0.3-0.7% |
0.3-0.7% |
0.3-0.7% |
main Electric motor power |
Y132m-6-5.5KW |
Y160m-6-7.5KW |
Y160m-6-7.5KW |
vibration electric motor power |
0.37KW |
0.37KW |
0.37KW |
Accelerating metering pump |
pneumatic |
pneumatic |
pneumatic |
Electric Voltage |
380V |
380V |
380V |
|
Overall dimension(mm)
|
1280x700x1280 |
2000X800X1300 |
2000X800X1300 |
Whole weight |
700kg |
800kg |
900kg |
wheel |
Nylon wheel ;Rubber wheel ;skid wheel ;Rail wheel |
||
