Specifications
mortar jet grouting pump>make cement pump 10years
>grout fireproof mortar,insulation
>no leakage,no pollution
>CE, ISO9001
UBJ1.8 Mortar jet grouting pump
The UBJ series peristaltic pump,squeeze mortar pump, integrating the functions of press grouting, conveying, grouting, spouting and plastering etc. altogether, is characterized in average discharging speed, high pump conveying pressure, long distance, high production efficiency and pressure grouting. With good spouting effect, the pump sets with a twice agitator to directly convey the mixed mortar into the pump chamber without disintegration and deposit, eliminating the common phenomenon of mortar blocking for the mortar, being widely used for engineering of construction, highway, tunnel, bridge, water conservancy, mine and line, etc.
Technical parameters
Model |
UBJ1.8-P |
UBJ3-P |
Output |
1.8m3/h |
3m3/h |
Delivery pressure |
15bar |
20bar |
Motor power |
2.2/2.8kw |
2.2/3.3/4kw |
Maximum grain size |
4mm |
4mm |
Horizontal delivery distance |
40m |
60m |
Vertical delivery distance |
20m |
30m |
Net weight |
350kg |
430kg |
Dimension(LxWxH) |
1400 x 800 x800mm |
1900 x 900 x900mm |
1. No need attach extra air compressor for spraying fireproof, thermal insulation, fireglass etc.
2. Ubj1.8 have been used for spraying fireproof to Steelhouse factory in 3years in Wenzhou Binhai development zone.
