Specifications
MP22 plaster spray equipment1.adopt German technology
2.plaster height:20m&distance:50m
3.includes water pump, air pump
MP22 plaster spray equipment
1. JP22 is small machine introduced German technology.
2. It sets water pump and water measuring function. It has the combined function of automatic mixing, pumping, bonding, plastering.
3. It’s suitable for construction of different characteristics and use of dry ready-mixed mortar including internal and external wall mortar, thermal insulation mortar, self-leveling mortar, bonding mortar, repairing mortar etc.
4.It sets the pressure controlling protection mechanism and achieves the remote control. With modular and compact structure, it's easy to dissemble.
5.Due to its small volume, it's easy move and adapt for use in narrow spaces.
Technical parameter
Model |
— |
JP22 |
Supply power |
— |
400V 50Hz |
Motor power |
kw |
4 2.2 |
Maximum grain size |
mm |
4 |
Output |
l/min |
25 |
Delivery pressure |
bar |
40 |
Horizontal delivery distance |
m |
40 |
Vertical delivery distance |
m |
15 |
Hopper volume |
L |
50 |
Net weight |
kg |
185 |
Dimension (L×W×H) |
mm |
1200×660×1100 |
1. JP22 can discharge into several parts which is very easily to clean, maintance and carrying to different floors.
2. JP22 are approved CE and ISO9001:2008 certificates.
