800-1000m2 per 7hrs JP40-L plastering machines used for EPS or 3D panels

Specifications

plastering machines used
1.CE Plastering machine
2.10 years experiences
3.380V,220V,240V
4.1200m2 in 8hours







1. JP40-L is small plastering machine introduced Italian technology.



2. It's applied for various characteristics and use of ready-mixed dry mortar construction.



3. It offers combined functions of mixing, pumping, bonding and plastering.



4. It can plaster and grout various interior and exterior plastering mortar, masonry mortar, flooring mortar, decorative mortar, thermal insulation mortar, and floor surface mortar.



5. JP40-L can max hegiht to 15m and distance to 30m, max grain size is 4mm. Plastering speed is 800-1000m2 per 8hours.







Technical parameters



Model	—	JP40-L
Supply power	—	400V 50Hz
Motor power	kw	3.3/4 3.7/4.4
Maximum grain size	mm	5
Output	l/min	30
Delivery pressure	bar	30
Horizontal delivery distance	m	60
Vertical delivery distance	m	20
Mixer power	kw	1.1
Mixer volume	l	120
Hopper volume	L	100
Net weight	kg	280
Dimension (L×W×H)	mm	1650×700×1140



























































1.  JP40-L can be used for different working purposes, plastering mortar, thermal insulation, fireproofing material.



plastering fireproofing material on steelhouse wall.









 JP40-L can be used for grouting in bridge, tunnel, buliding foundation.









2. JP40-L the design is very sample and easily to keep mainatance
