Putty mortar spraying machine
1. JP40-L is small plastering machine introduced Italian technology.
2. It's applied for various characteristics and use of ready-mixed dry mortar construction.
3. It offers combined functions of mixing, pumping, bonding and plastering.
4. It can plaster and grout various interior and exterior plastering mortar, masonry mortar, flooring mortar, decorative mortar, thermal insulation mortar, and floor surface mortar.
5. JP40-L can max hegiht to 15m and distance to 30m, max grain size is 4mm. Plastering speed is 800-1000m2 per 8hours.
Technical parameters
Model |
— |
JP40-L |
Supply power |
— |
400V 50Hz |
Motor power |
kw |
3.3/4 3.7/4.4 |
Maximum grain size |
mm |
5 |
Output |
l/min |
30 |
Delivery pressure |
bar |
30 |
Horizontal delivery distance |
m |
60 |
Vertical delivery distance |
m |
20 |
Mixer power |
kw |
1.1 |
Mixer volume |
l |
120 |
Hopper volume |
L |
100 |
Net weight |
kg |
280 |
|
Dimension (L×W×H) |
mm |
1650×700×1140 |
1. The handle is designed for easily falling wet mortar from mixer to feeding hopper.
2. The mortar mixer can be moved with two parts including mixer and screw mortar pump. You can move it very easliy in different floors.
3. JP40-L the design is very sample and easily to keep mainatance
4. JP40-L screw mortar pump is stator and rotor system.
Mortar hose, air hose and other accessories
5. JP40-L can be used for different working purposes, plastering mortar, thermal insulation, fireproofing material.
plastering fireproofing material on steelhouse wall.
JP40-L can be used for grouting in bridge, tunnel, buliding foundation.
