Specifications
Tipping Trailers for the transportation of large volumes per trip.Tantri manufacture dump bodies for trucks, Tipping trailersAll with world famous brands of Hydraulics.
Specifications:
Trailer weight - 11,760 kg (unladen)
Loading capacity - 45 Cbm
Dimension - Length 10,275mm, Width 2440mm, Height 3025mm
Main frame - High tensile steel 350 x 350 x 16 x 10mm (main “I” beam) and 150 x 75 x 6mm ( cross members)
Loading bucket - 5mm high tensile steel integrated bucket (Length 9255mm, Height 1775mm)
Hydraulic system - Hydraulically tipping system with rear opening door
Landing legs - 80,000 kg Static loading capacity
King pin - 50mm Dia forged steel king pin
Lights - LED 24V light system (signal, brake, parking & number plate)
Paints - Shotblasted and Painted with Epoxy primer coating and customer choice color topcoat
Running Gear:
Axles - 3 x 13 tons capacity square beam axles
Suspensions - Tridem suspensions system (06 Nos. leaf spring bundles)
Brakes - Pneumatic brake system
Wheels - 12 Nos. 9.00x22.5 10 hole disc wheels
Tires - 12 Nos. 12R 22.5 (Radial)
Including: Options :
Spare wheel with carrier Additional spare wheel carrier
Steel mudguards with flaps
Safety luminous fittings
