Help CenterAnti-acid / Anti Alkali Glass Fused to Steel Tank for Wastewater Treatment
Related Products
-
Anti Corrosion Glass Lined Steel Bolted Tank With Wide Range of Color OptionsUS$ 5,000 - 50,000MOQ: 1 Unit -
Acid and Alkali Proof GFS Short Construction Wastewater TankUS$ 5,000 - 50,000MOQ: 1 Unit
-
Low Maintenance Wastewater Treatment Plant Equipment for CSTR ReactorUS$ 5,000 - 50,000MOQ: 1 Unit
-
High Corrosion Domestic Wastewater Treatment With More Than 30 Years Service LifeUS$ 5,000 - 50,000MOQ: 1 Unit
-
High Corrosion Type of Wastewater Treatment Plant With More Than 30 Years Service LifeUS$ 5,000 - 50,000MOQ: 1 Unit
About the glass fused to steel tanks for wastewater treatment
The steel round (cylindrical) shell of the tank is built from two-layer enameled sheets coated on both sides. The sheets are attached with special high-grade bolts and sealed by constantly flexible silicone (sealant). The surface of connecting material and the shell itself are properly treated.
| Product Name |
glass fused to steel waste water treatment tank up to 18600 m3 |
| Coating Color | dark green, white, blue, color can be customized |
| Coating Thickness | 0.25~0.40mm ,double coating |
| Acid and alkalinity proof | Standard sheet PH:3~11 |
| Special sheet PH: 1~14 | |
| Adhesion | 3,450 N/cm |
| Elastic | Same as steel sheet,around 500 Kn /mm |
| Hardness | 6.0 ( Mohs ) |
| Service life | ≥30Years |
| Holiday test | >1500v |
| Permeability | Gas / liquid impermeable |
| Easy to clean | Teh Smooth, glossy, inert, non adhesive |
| Corrosion resistance |
Excellent, suitable for wastewater, sewage treatment plant ,salt water,sea water,high-sulfur crude oil,salt fox,organic and inorganic compounds |
| Advantages |
- short construction period |
Except for waste water treatment, the enamel steel tanks also can be used in blow field:
2. FOOD : Flour , Sugar , Meals : Soybean , Bone , Fish , Corn , Meat , Blood , Dried Distillers Grain , Starch , Salt , Milk Solids storage.
3. MINERAL and GRAIN STOARGE: Lime , Barite , Perlite , Bentonite
4. PETROLEUM PRODUCTS : Crude Oil Storage , Drilling Fluids , Mud, Waste water , Distillates , Fuel Oil , etc.
5. CHEMICALS : Carbon Black , Activated Carbon , Sodium Carbonate , Soda Ash , Fly Ash , Cement , Sodium Hydroxide , Urea Pellets , Sodium Nitrate , Coke , Glass , Potassium Carbonate.
6. BIO-FUELS : Yeast Tank , Yeast Tank ,Caustics , Syrup , Raw Feed stock Oils , Glycerin , Methanol , Lime , Bulk Bio-Diesel , Fire Protection , Process Water , Waste water , Corn - Feed stock Storage , Dry Distiller's Grain
7. POWER GENERATION : Fly Ash Storage , Lime Storage , Load-Out Silo Structures , Treatment Bins & Silos , Systems , Coal Storage.
Part of our Projects of Enamel steel tanks shows :
-- 2008 Beijing Olympics Games wastewater project
-- 2009 Niger Azelik uranium deposits(China National Nuclear Corporation)
-- 2009 Niger Azelik uranium deposits(China National Nuclear Corporation)
-- 2009-2013 Palm oil wastewater treatment project in Indonesia
-- 2011 Anyang city Biogas project
-- Chengde Biology waste water project
-- Brewery wastewater treatment
-- Shandong Garbage waste water treatment project
-- Pharmacy waste water treatment project
-- 2013 Sichuan Chengdu Pharmaceutical wastewate treatment
-- 2014 Urban sludge treatment project- Kazakhstan
Outstanding advantages of our glass fused to steel wastewater treatment tank
| Comparison of various tank characteristics - 1 | ||||
| Name | Concrete Tank | Carbon steel tank |
Enamel tank (Glass-fused-to-Steel tanks) |
LIPP tank |
| Beautiful degree | Low | Low | High | High |
| Temperature adaption | A stress |
Adapt to low temperature |
Adapt to low temperature |
Adapt to low temperature |
| Shape | Any shape | Round shape | Round shape | Round shape |
| Ground Or underground | Both | Ground | Both | Ground |
| Corrosion resistance | Normal | No resistance to corrosion | Good | Not |
| Abrasion resistance | Good | Bad | Good | Bad |
| Easy to clean | Bad | Bad | Good | Normal |
| Easy to repaire | Normal | Good | Good | |
| Weight (T) | heavy | Little heavy | light | Little light |
| Tank cost | middle | high | low | low |
| Tank temperature protect | no | need | need | need |
| Anti-corrosive Treatment | no | need | no | need |
| Annual anticorrosive cost | no | High cost | no | High cost |
| Corrosion resistance | normal | no | superior | normal |
| Abrasion resistance | good | bad | good | bad |
| Service life | 30 | 10 | 30 | 25 |
Double checking is required before packaging, confirm the plate’s code and quality. The steel plates is separated with each other by PE foam, to avoid any damage on the coating surface. And the whole pallet steels packed in wooden case.
Center Enamel is the world leading manufacturer of glass fused bolted steel storage tank. We have our own factory cover 80,000 square meters and own our R&D team. Our factory has over 26 years experience in producing Enamle products.
We already passed ISO9001-2000 quality system certification, and product and design can reach AWWA D103-09 standard, OSHA and meet European standards. We are the only enterprise that can produce AA grade (acid-proof and alkali- proof ) enameled sheet now
And in a detail-oriented and pursuing perfect belief, we insist in providing the highest quality products and best services. Now we are supplying products services for all over the world.
Quality is our culture and the soul of our enterprise
Our strict quality control system ensure the consistent delivery stable quality product all the time. There are more than 50 staffs in our quality control department. The QC control system is in accordance with the requirement of ISO9001. All the enamel tank & storage silo manufactured by center Enamel should pass belwo 4 kinds of quality tests from the beginning of produce to delivery and make sure each product is high quality.
Any questions will be replied within 24 hours
Dear friends, should you have any questions about our glass fused to steel tank , please feel free to contact with us. Wish to help you. Have a nice day.
Gabby Xuan
Skype: Gabby8427
Mobile /whatsapp: +86 18620551151
E-mail : zztank_gabby(at)
Tel : 86-20-34061259
