Help CenterLSY180 Screw Conveyor Flight Manufacture
Related Products
Specifications
Type:LSY180 screw conveyor flight1.Competitive price
2.Any coastal port is OK
3.Excellent quality
4.Best sale service
Features of screw conveyor flight:
1.Screw conveyor adopts excellent quality steel pipe with great property.
2.The dual blades pitch decrease the compressed material degree when conveying.
3.Adopt first grade reducer ,heavy type design ,low noise ,long rotation distance.
4.Optional universal ball joint and make installation adjust to convenience .
5.Match good quality crane and tail bearings for convenient installation.
6.Enough spare components with various specification.
7.There are plenty of stock with diameters of 165mm,219mm,273mm,323mm,407mm .And the special size can be manufactured according to customer's requirements.
8.Standard components assembly is convenient to deliver.
Application of screw conveyor flight :
It is widely used in various industries ,such as construction material , chemical industry , electric power,metallurgy, coal carbon,food and so on .It is applied to convey powder, graininess and small block material with level or incline.
Parameters of LSY163/180/219/230 screw conveyor flight:
Type: |
LSY-219 |
Diameter(mm) |
219 |
Producing capacity(t/h) |
20 |
Power(Kw) |
7.5Kw |
Weight(Kg) |
700 |
Best screw conveyor price for different types !
Screw Conveyor Type |
LSY163 |
LSY180 |
LSY230 |
Spiral Diameter(mm) |
163 |
180 |
230 |
Rotation Speed(r/min) |
150 |
170 |
180 |
Housing Diameter(mm) |
194x6 |
219x8 |
273x8 |
Carrying Capacity(t/h) |
16 |
18 |
23 |
Conveying Length(m) |
2-12 |
2-13 |
2-15 |
Working Angle |
0-60 |
0-60 |
0-60 |
Motor Type |
Y132M-4 |
Y160L-4 |
Y160L-6 |
Power(kw) |
7.5 |
11 |
15 |
We are a manufacture of construction machine and mine machine, with more than 30 years experience , mainly produce concrete batching plant, AAC production line,stabilized soil mixing plant,sand production line,dry mortar production line,cement production line, concrete mixer,concrete pump ,concrete truck,belt conveyor,cement silo ,jaw crusher,impact crusher ,raymond mill ,sand washing machine and so on .
If there is anything to do for you , we shall be more than pleased to do so .
Our manufacture products have got the BV certificate and screw conveyor price is much competitive .
