Specifications
Foam concrete blocks TF-251.30Years Experience
2.CE/CV/BO
3.Easy to operate
4.Production capacity:25CBM/h
Foam concrete blocks TF-25 foam concrete mixer-Factory direct
1. Introduction of TF-25 foam concrete blocks
TF-25 foam concrete mixer composed by loading transmission equipment, concrete mixer and foam conveying equipment. This foam concrete mixer adopts the automatic during the operation process.
2. Technical feature of TF-25 foam concrete blocks
TF-25foam concrete mixer adopted duplex hydraulic pump to convey cement which outlet pressure high can meet the needs of the high-rise building;
Ratio of various kinds of ingredients adopts full-automatic control, the density of foamed cement is easy to adjust.
Using a selection of form a complete set of imported high-quality components, reliable quality, after-sales service guaranteed.
3. Performance characteristics of TF-25 type pump
1) adopt wear-resisting metals, strong and durable.
2) ratio of various kinds of ingredients adopts full-automatic control, the density of foamed cement is easy to adjust.
3) adopt famous brand of high quality components, quality is reliable.
4) adopt hydraulic double cylinder reciprocating one-way transmission form to delivery foam concrete to site, the flow is stable and the fluctuations is small.
5) with road wheel, move and take place is convenient and flexible.
6) electric cabinet is equipped with remote control handle, the operation is very convenient.
4. Parameters of TF- 25 type pump
Component |
Item |
Parameter/Model |
|
concrete mixer |
Production capacity |
25m³/h |
Capacity |
0.8 m³ |
|
Driving power |
4.0kw |
|
Rotating speed |
39r/min |
|
Foam pump |
f p-Ⅱ |
|
Feeder |
belt conveyor |
|
Working form |
continuous |
|
|
delivery pump |
transportation volume |
25 m³/h |
Max vertical conveying height |
150m |
|
Max horizontal delivery distance |
500m |
|
Main motor power |
22kw |
|
motor power of feeder |
3kw |
|
Mixing feeding height |
1000mm |
1.Delivery time: 15 days after receipt of your deposit.
2.Payment terms: 30% T/T in advance, the balance is paid (by T/T) before delivery.
3.Package:
1).Wire cables are used for fastening the machine on the trailer or inside the container.
2).Cork wood are placed in front or behind the machine to protect it.
3).Plastic film is covered on the machine as a rain-roof.
4).Crane is used during the whole loading.
Why chose Henan Teng Fei?
1.Teng Fei give priority to with construction company, during years of construction equipment, progress in practice and has strong practicability.
2.Our company has years of experience in project negotiation and can provide customers with effective business negotiations guidance to win project
3.in addition to providing equipment and technical training, we also provide free foam concrete project system solutions to help you get maximum benefit.
How long is the warranty?
The warranty period is 12 months.
What services does it provide?
1.pre-sale service: our company can provide technological guidance and formulate suitable equipment matching program according with your specific production requirements.
2.on-purchase service: our company can solve professional technical problems and other related issues for you.
3.after-sales service: our company provides that engineers available to service machinery overseas and equipment for life maintenance.
What is the Teng Fei’s basic philosophy?
Henan Teng Fei Machine Manufacturing Co., Ltd. is a collection of scientific research, development, production marketing for the integration of manufacturing enterprise; The company execute principles “development is a competition philosophy” and take “efficient, pragmatic, cooperation, innovation “as beliefs.
