Specifications
AAC concrete block machine1.Light weight
2.Fire -proof
3.Automatic aac cutting machine
4. ISO 9001 Certifica
AAC concrete block machine-50000-300000 CBM AAC wall panel machine-Professional production
1. Basic Introduction of AAC concrete block machine :
Main raw materials of AAC are siliceous material (sand, fly ash and Silicon tailings) and Calcium materials (lime and cement) mixed with foaming agent (aluminum powder). It is the product of light porous silicate through the following processes: batching, mixing, pouring, hardening, cutting, autoclaving and curing etc. Because of large amount of well-distributed tiny pores after foaming, it is named autoclaved aerated concrete.
aerated autoclaved concrete plant, AAC block, aac production line, aac plant, AAC brick, autoclave aerated concrete block,concrete block machine, light weight block
2. AAC concrete block machine Classification :
In general, it can be classified according to the types of raw materials, manufacture process and functions. Based on the shape of AAC products, it can be divided into: AAC blocks and AAC panels. It is a revolutionary material offering an unique combination of high durability and strength, low weight, excellent heat insulation, fire resistant, noise absorption, unprecedented build ability and superior ecological green features. In China, AAC is one of the light wall materials which was popularized and applied at the earliest and the most widely.
3. Advantages of AAC concrete block machine :
3.1. Low weight: holes gap: 70%~80%; volume density: 400~700kg/m3,1/4 of common cement ,1/3 of fireclay brick and 1/2 air brick, able to float like wood, and to reduce building weight and low building comprehensive construction cost.
3.2. Fire resistant: well fire resistance performance without harmful gas when fired; able to resistant 700°,225mins for 100mm wall and 480mins for 200mm wall.
3.3. Noise absorption: absorbing noise with porous structure; 100mm can absorb 41 decibel.
3.4. Heat insulation: excellent heat insulation with large amount of holes and micro pores; coefficient of thermal conductivity: 0.11-0.16W/MK, 1/4-1/5 of fireclay brick.
3.5. Anti-permeability: low water-uptake for the materials consist independent pores
3.6. Anti-seismic: comparing to fireclay brick, AAC can increase 2 seismic levels.
3.7. Ecological green: no pollution during manufacture, transportation and application; protect farm land, save energy and reduce consumption.
3.8. High durability: stable strength
3.9. Easy workability: unprecedented build ability offers advantages to construct
3.10. Economic: comparing to fireclay bricks, AAC reduces 5% comprehensive construction cost
4. Performance of AAC concrete block machine :
Finished AAC block is Suitable for all nonbearing wall and bearing wall of multi-story (less than six-floor), nonbearing wall internal parting wall, thermal insulation rooms front panel, floorslab.
4.1, Unit weight grade (kg/m3): 500, 600, 700, 800 (means 05,06,07,08 grade)
4.2, Compression strength grade (Mpa): A3.5, A5.0, A7.5, A10.0 (1Mpa=10kg/m2)
4.3, Drying shrinkage (mm/m): ≤ 0.8
4.4, Heat conductivity(w/m.k): 0.09-0.22
4.5,Sound-proofing performance(db): 40-47.75
Conforming with China national standards GB11968-1997 (the latest AAC block national standard)
5. Normal size of AAC concrete block machine :
Length (mm): 600
Width (mm): 75, 100, 125, 150, 175, 200, 250
60, 120, 180, 240
Height (mm): 200, 240, 250, 300
Remarks: the size can be customized
6. AAC concrete block machine Process:
1.Delivery time: 15 days after receipt of your deposit.
2.Payment terms: 30% T/T in advance, the left is paid (by T/T) before delivery.
3.Package:
1).Wire cables are used for fastening the machine on the trailer or inside the container.
2).Cork wood are placed in front or behind the machine to protect it.
3).Plastic film is covered on the machine as a rain-roof.
4).Crane is used during the whole loading.
Why chose Henan Teng Fei?
1.Teng Fei give priority to with construction company, during years of construction equipment, progress in practice and has strong practicability.
2.Our company has years of experience in project negotiation and can provide customers with effective business negotiations guidance to win project
3.in addition to providing equipment and technical training, we also provide free foam concrete project system solutions to help you get maximum benefit.
How long is the warranty?
The warranty period is 12 months.
What services does it provide?
1.pre-sale service: our company can provide technological guidance and formulate suitable equipment matching program according with your specific production requirements.
2.on-purchase service: our company can solve professional technical problems and other related issues for you.
3.after-sales service: our company provides that engineers available to service machinery overseas and equipment for life maintenance.
What is the Teng Fei’s basic philosophy?
Henan Teng Fei Machine Manufacturing Co., Ltd. is a collection of scientific research, development, production marketing for the integration of manufacturing enterprise; The company execute principles “development is a competition philosophy” and take “efficient, pragmatic, cooperation, innovation “as beliefs.
