Home > Products > BALL WINDER > Multi-heads ball winder: https://youtu.be/dgLn6ZkZtJA
Multi-heads ball winder: https://youtu.be/dgLn6ZkZtJA
- 10 Set / Sets per Month
- Qingdao/Shanghai
- T/T D/P D/A
Product Details
Condition: | New | Product Type: | Plastic Rope | Place of Origin: | Shandong, China |
Brand Name: | ROPE NET | Model Number: | RMBL-06-160/RMBL-10-150/RMBL-12-150 | Voltage: | 220v/380v |
Power(W): | 2.54kw | Dimension(L*W*H): | 3.6X1.1X1.15m | Weight: | 500KG |
Certification: | CE/ISO9001 | Warranty: | 1 Year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Multi-heads Ball Winder/Multi-heads Ball Winding Machine
Product Application
The machine is suitable for winding different size of PP split-film, flat yarn, cotton into ball shape. The machine can realize count automatically, multi-heads working at the same time.
* Multi balls working at the same time
* PLC control, easy to operate
* Different ball shape
* Easy to maintain
* Durable and stable
Model | RMBL-06 | RMBL-10 | RMBL-12 |
No. of Heads | 6 | 10 | 12 |
Flyer Speed | 0-650rpm | 0-650rpm | 0-650rpm |
Winding Speed | 5-70rpm | 5-70rpm | 5-70rpm |
Size of Nylon Bobbin | ø21 X ø27 X 205mm | ø21 X ø27 X 205mm | ø21 X ø27 X 205mm |
Max. Outline Size of Ball | ø160 X 160mm | ø150 X 150mm | ø150 X 150mm |
Weight | 370kg | 480kg | 520kg |
Related Machines we produce:
Automatic Ball Winding Machine:
SHANDONG ROPE NET MACHINERY :
1. Established in the year 2002, with more than 1000 empoyees, As a professional manufacturer of rope machines more than 10 years!
2.We are the largest and most professional manufacturer which can produce a
complete set of rope making machines in China. Now we are the ropeking in China
Products Including:
1) Plastic Monofilament extruder
2) Plastic Film extruder
3) Ring twister.
4) High speed twisted rope making machine
5) High speed braided rope making machine
6) High speed ball winder including single head and multi-heads(for Plastic PP
tape twine&Cotton twine&Sisal twine&Jute twine)
7) Spool winder machine
8) Coiler machine
9) Hank winder machine.
10) Shrinking machine.
11) Strapping machine.
