New Product High Speed Round Rope Braider Machine

Name: New Product High Speed Round Rope Braider Machine
Brand: lutong
SKU: 139765247
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Product Type:

Plastic Rope

Place of Origin:

Shandong, China

Laizhou Lutong Plastics Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

qingdao

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Product Type Plastic Rope

Place of Origin Shandong, China

Brand Name lutong

Model Number M-type

Voltage 220v/380v

Power(W) 5.5kw

Weight 2500kgs

Certification BV

Warranty One year

After-sales Service Provided Engineers available to service machinery overseas

Specifications

rope making machinery
rope making with strand making as a union.
3/4 strands are available
make rope with dia.20-30mm

high speed round rope braider machine rope making machine

This machine is suitable for making ropes with Nylon, PE, PP, etc. yarns or strands

It consists of rope making device and strand making device

can produce rope with Dia.4-28mm after continuous operation once

omit extra working steps from strand making to rope making, thereby the production efficiency is greatly improved.

There is no waste yarn or scrap coming out during the production process, so the ropes are more attractive and durable.

Technical data	Revolution of principal axis (r/min)	Dia of rope(mm)	Automatic Lining machine	Twist (t/m)	Direction of twist	Motor power	Dimension (m)	Output (t/day)
M77	320	20 -26	GP40	16-62	→	18KW-4	12* 2.3* 2.1	1.5-2
M66	350	16 -22	GP40	16-62	→	15KW-4	9* 2.1* 2.1	0.9-1.5
M55	420	10 -16	GP30	16-62	→	7.5KW-4	6.86* 2 * 2.1	0.8-1.1
M44	620	5 -8		16-62	→	5.5KW-4	5* 1.9* 1.8	0.3-0.6
M33	900	3 -6		26-82	→	3KW-4	4* 1.9* 1.8	0.2-0.4
