Specifications
pp yarn produce machine1.Takes up small area
2.Simple operation
3.High output
4.Easy to maintain
pp yarn produce machine
This series extruder can produce many kinds of fiber by different screw and related equipments,
such like HDPE and PP monofilament fiber, danline fiber, flat film fiber, split film fiber, The fibers
can be used for the manufacturing of industry, fishing industry and civilian use, such like rope,
fishing net, construction safety net, PP bag and etc.
1. Main technical parameter
| Item | HDYSJ-90*30 |
| Screw Diameter | 90mm |
| Ratio of L/D | 30:1 |
| Ratation Speed of Screw | 20-120r/min |
| Fiber Diameter | 0.20mm-0.40mm |
| Max Extruding Capacity | 2.5tons/24h |
|
Dimension of Machine (L*W*H) |
30(m)*2(m)*2.5(m) |
| Fiber Type |
HDPE and PP monofilament fiber, danline fiber, flat film fiber, split film fiber |
| Screw and Barrel |
Screw and barrel are made of nitride steel 38CrMoAl with special hardening, with
a good corrosion resistance and wear resistance |
| Cooling Type | Water cooling |
2. Flow Chart of pp yarn producing machine :
Raw material ----------Extruder------------water cooling--------stretching-------heating
---------stretching-----------guide roller----------winder.
3. Installation:
We will send our technicians to your factory for installation, adjustment and training. Customer
should bare all the charge such as round ticket, accommodation, food etc.
4. Guarantee Systerm and Matenance
One year guarantee for the machines except the spare part, we will supply lifelong technology
service to solve any problems from you during the guarantee time, not because man-made
sabotage, we will change the parts for free, but customer should pay the delivery cost.
5. Picturer Show of monofilament yarn drawing machine
6.Our garden-style factory
We can supply " the Complete Project for the ROPE MAKING UNIT."service.
PP extruder (pp fiber)----Ring twister (strand)---Rope Making Machine (twisted rope, braided
rope)---Packaging spool winder, ball winder, hank machine, coil machine)
Any suggestions from you will help us so much. please feel free to contact me for more information.
